VENOEN ITX Fanless Mini PC, Core i5 10210U, Industrial PC W11 Pro, 16GB RAM 1TB SSD, HD+EDP+USB-C, 4K 3 Display, RS232/RSS485 COM, Dual LAN, M.2 Slot 4G/5G Model, WiFi AC, BT4.2, Auto Power On
- Core i5 10210U and W11 pro Fanless Industrial PC with 10th Core i5 10210U (4-core 8-thread, 1.60Ghz up to frequency 4.20GHz), pre-installed W11 pro. Powerful performance processor makes Venoen PC a ultra fast & smooth & power-saving mini PC which is effortless satisfy your daily entertainment, Games, office, education industry etc.
- Memory and Storage Capacity Expansion Venoen Industrial PC is equipped with 2 x DDR4 RAM slot, MAX 64GB; And 1 * M.2 2280 NVME/SATA SSD + 1 * SATA3.0 for 2.5inch HDD/SSD dual hard drive design greatly enhances storage functions, simplifies data management, you can expand the storage as your demand, Large storage drives Small Case PC runs smoothly without waiting.
- Multifunction & Powerful Fanless PC i5 W11 Pro with Dual RJ45 Lan, HD1.4(4K 30HZ), EDP(4K 60HZ), Type-C(4K 60HZ), 2x RS232 COM, 2x 6pin GPIO, 4x RS232/RS485/RS422 COM, 2x DB9 Can Bus(Controller Area Network), 4x USB 3.0, 4x USB 2.0, 1x SIM Card hole, SPK/MIC, 19V DC IN, Alum
+
+
Overview
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
H4T Fanless Industrial PC Small Desktop PC Specifications:
CPU:
Core i5 10210U, 4 Core 8 Thread, 1.60 GHz to 4.20 GHz, UHD Graphics
Memory: 2* DDR4 slots on board; MAX 64GB
Storage: Support 1* M.2 2280 NVME/SATA SSD + 1* 2.5 SATA hard drive together
Ethernet: 2* RJ45 Gigabit Ethernet NIC
In-out interfaces:
Switch: 1 x On/Off switch
Display: HD1.4 + EDP + Type-C, Support 3 monitors
USB: 4*USB 3.0 port; 4*USB 2.0 Port
Serial port: 4* RS232/RS485/RS422 + 2* RS232 COM port
CAN BUS: 2* 9pin CAN BUS (Controller Area Network) port
SIM: 1 x SIM card slot (standard without SIM card)
Wifi: M.2 2230 Slot, Support Dual Band Wifi and BT model
Wireless: M.2 Slot, Support 4G/5G Module, 42x30mm/52x30mm
Feature : FP1 9Pin onboard, support connect extranal switch
Other:
Dimensions: 230*182*65 mm
Weight: Net 1.8 kg, gross 2.5 kg
Temperature: -20 to 85
Humidity: 0%~ 95% relative humidity
Material: Brushed aluminum alloy housing
Language: Multilingual
Function: Supports Hardware Auto Power On, Wake System from RTC Alarm, PXE(UEFI only), Watchdog, Network Wake-up, Diskless Boot, Temperature Management
Virtualization Application: This fanless mini PC is applicable to industrial computer, soft routing, virtualization, thin client, edge computing, visual inspection, industrial control, cloud server etc.
Package contents:
1 Mini PC; 1 power supply; 4 Antennas, SATA Cable, 1 HD Cable
CPU:
Core i5 10210U, 4 Core 8 Thread, 1.60 GHz to 4.20 GHz, UHD Graphics
Memory: 2* DDR4 slots on board; MAX 64GB
Storage: Support 1* M.2 2280 NVME/SATA SSD + 1* 2.5 SATA hard drive together
Ethernet: 2* RJ45 Gigabit Ethernet NIC
In-out interfaces:
Switch: 1 x On/Off switch
Display: HD1.4 + EDP + Type-C, Support 3 monitors
USB: 4*USB 3.0 port; 4*USB 2.0 Port
Serial port: 4* RS232/RS485/RS422 + 2* RS232 COM port
CAN BUS: 2* 9pin CAN BUS (Controller Area Network) port
SIM: 1 x SIM card slot (standard without SIM card)
Wifi: M.2 2230 Slot, Support Dual Band Wifi and BT model
Wireless: M.2 Slot, Support 4G/5G Module, 42x30mm/52x30mm
Feature : FP1 9Pin onboard, support connect extranal switch
Other:
Dimensions: 230*182*65 mm
Weight: Net 1.8 kg, gross 2.5 kg
Temperature: -20 to 85
Humidity: 0%~ 95% relative humidity
Material: Brushed aluminum alloy housing
Language: Multilingual
Function: Supports Hardware Auto Power On, Wake System from RTC Alarm, PXE(UEFI only), Watchdog, Network Wake-up, Diskless Boot, Temperature Management
Virtualization Application: This fanless mini PC is applicable to industrial computer, soft routing, virtualization, thin client, edge computing, visual inspection, industrial control, cloud server etc.
Package contents:
1 Mini PC; 1 power supply; 4 Antennas, SATA Cable, 1 HD Cable
