Industrial Computer, Fanless Mini PC, Embedded IPC, N3510 N3520 N3530 N3540, BM18, Watchdog, GPIO, WOL, SIM Slot, 2 x LAN, 2 x RS232 422 485, 8G RAM, 256G SSD, 1TB HDD
- Compact, fully functional, all the power and functionality of a desktop computer in a compact, stylish chassis, powered by intel quad coren3510 n3520 n3530 n3540 processor. TDP is around 7.5-10w, power saving and space saving
- Windows 11 pro 64 bit installed, set up is effortless and it's ready to run straight out of the box
- Fanless passive cooling design, silent solution that\u2019s ultra energy-efficient. the advanced fanless passive cooling design maximizes heat dissipation, meaning all operations can be conducted in absolute silence
- HUNSN BM18 designed with vga, hdmi, 2 x usb 3.0, 4 x usb 2.0, 2 x lan,2 x com ((rs232 rs422 rs485 soft switching), sim card slot, spk, mic, industrial aesthetic design and reasonable interface layout, support automatically power on after power failure
- Size at 175 x 130 x 36mm, 1.5kgs, 12v 3a power supply, with power cord, all use a big brand memory and ssd/hdd with quality assurance, very powerful fanless mini pc
+
+
Overview
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Model Number:HUNSN BM18
Material:Aluminum
CPU:Intel Quad Core N3510 N3520 N3530 N3540, ship one of them
Memory:1 x SO-DIMM DDR3L1333, max. 8GB RAM
Storage:1 x mSATA SSD, 1 x 2.5 Inch SATA SSD/HDD
Expansion:1 x half size mini pcie for WiFi, 1 x full size mini pcie for 3G/4G
Audio Card:ALC892
Network Card:2 x Intel i211 10/100/1000 BaseT LAN
WiFi:802.11ac 2.4 and 5Ghz
Bluetooth:4.0/4.2
I/0 Port:2 x LAN, 2 x COM (RS232 RS422 RS485), VGA, HDMI, 2 x USB 3.0, 4 x USB2.0, Mic, Spk, Front SIM Card Slot
Power:DC100-240V AC/50-60Hz, DC 12V/3A
Operating Temperature:0°C~70°C Centigrade (32°F~140°F)
Storage Temperature:-20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity:10%~90% (non-condensing)
Vesa Mount:Optional
Weight:1.5kgs
Measurement:175 x 130 x 36mm
TDP:7.5-10W
Cooling system:Fanless
Packing List:HUNSN BM18 mini pc, power supply, power cord, WiFi antennas, warranty card
Function:1.Support 4G module with SIM card slot
2.Support soft switching 2 RS232 to RS422 RS485 in BIOS.
3.Support 256-level watchdog
4.Support 8 bit GPIO
5.Support diskless boot/restore AC power loss/wake on lan function
6.Support dual screen (VGA and HDMI) for simultaneous display or synchronous different display
Warranty:3 years
System Support:Windows 7/10/11, Linux Ubuntu etc
System Default Option:Windows 11 pro in English
ATTENTION:Other options, Linux or other system, other system language, do leave HUNSN message on the order, thank you
Material:Aluminum
CPU:Intel Quad Core N3510 N3520 N3530 N3540, ship one of them
Memory:1 x SO-DIMM DDR3L1333, max. 8GB RAM
Storage:1 x mSATA SSD, 1 x 2.5 Inch SATA SSD/HDD
Expansion:1 x half size mini pcie for WiFi, 1 x full size mini pcie for 3G/4G
Audio Card:ALC892
Network Card:2 x Intel i211 10/100/1000 BaseT LAN
WiFi:802.11ac 2.4 and 5Ghz
Bluetooth:4.0/4.2
I/0 Port:2 x LAN, 2 x COM (RS232 RS422 RS485), VGA, HDMI, 2 x USB 3.0, 4 x USB2.0, Mic, Spk, Front SIM Card Slot
Power:DC100-240V AC/50-60Hz, DC 12V/3A
Operating Temperature:0°C~70°C Centigrade (32°F~140°F)
Storage Temperature:-20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity:10%~90% (non-condensing)
Vesa Mount:Optional
Weight:1.5kgs
Measurement:175 x 130 x 36mm
TDP:7.5-10W
Cooling system:Fanless
Packing List:HUNSN BM18 mini pc, power supply, power cord, WiFi antennas, warranty card
Function:1.Support 4G module with SIM card slot
2.Support soft switching 2 RS232 to RS422 RS485 in BIOS.
3.Support 256-level watchdog
4.Support 8 bit GPIO
5.Support diskless boot/restore AC power loss/wake on lan function
6.Support dual screen (VGA and HDMI) for simultaneous display or synchronous different display
Warranty:3 years
System Support:Windows 7/10/11, Linux Ubuntu etc
System Default Option:Windows 11 pro in English
ATTENTION:Other options, Linux or other system, other system language, do leave HUNSN message on the order, thank you
