$960.99
Meet Your Seller
Industrial Embedded Computer, Mini PC, J6412, IX20, 4 x RS232 485, 2 x HDMI, VGA, Expandable CAN GPIO 936V Wide Voltage, 8G RAM, 128G SSD
- Powered by j6412 processor, applicable to a wide range of industrial applications, 7 x 24 hours of stable work, application for industrial automation, medical, logistics, transportation, warehousing, e-education etc, with mount bracket
- Windows 11 pro 64 bit installed, set up is effortless and it's ready to run straight out of the box
- Fanless passive cooling design, silent solution thats ultra energy-efficient
- ANDAQI IX20 designed with power switch, 4 x usb3.0, 4 x com com1 com2 for rs232/485, audio, 2 x usb2.0, 2 x lan, 2 x hdmi, vga, dc_in, industrial aesthetic design and reasonable interface layout, support auto power on, timing boot, wake on lan, pxe boot, watchdog 0255 level, tpm2.0
- Size at 186 x 127 x 66mm, 1.36kgs, 12v5a power supply, with power cord, all use a big brand memory and ssd/hdd with quality assurance, very powerful fanless embedded computer
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
Model Number: ANDAQI IX20
Material: Aluminum
CPU: Celeron Processor J6412 1.5M Cache, up to 2.60 GHz
Memory: 1 x SODIMM DDR4 3200 MT/s, MAX. 32GB RAM
Storage: 1 x M.2 2280 M-key PCIE3.0 x1 SATA/NVME SSD, 1 x 2.5 Inch SATA SSD/HDD
Network: 2 x RTL8111H Gigabit LAN
Expansion: Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
WiFi: Wi-Fi 6 802.11AX
Bluetooth: 5.2
Optional Expansion: 936V wide voltage power, GPIO, CAN module, COM etc
I/0 Port: Power Switch, 4 x USB3.0, 4 x COM COM1 COM2 for RS232/485, Audio, 2 x USB2.0, 2 x LAN, 2 x HDMI, VGA, DC_IN
Power Supply: DC100-240V AC/50-60Hz, DC 12V5A
Operating Temperature: -20°C ~ +50°C, surface air flow
Working Humidity: 5%~95% non-condensing
Size: 186 x 127 x 66mm
Weight: 1.36kgs
Consumption: 10W
Cooling system: Fanless
Function: Support Auto power on, Timing boot, Wake on LAN, PXE boot, Watchdog 0255 level, TPM2.0 security encryption
Packing List: ANDAQI IX20 embedded computer, power supply, power cord, WiFi antennas, mount bracket, warranty card
Installation: Supports Desktop, Din Rail, wall-mounted and other fixing methods, default as vesa mount method,
if need Din Rail, please refer to Din Rail type
System Support: Windows 10/11, Linux Ubuntu
System Default Option: Windows 11 pro in English
ATTENTION: Other options, Linux or other system, other system language, do leave ANDAQI message on the order, thank you
Material: Aluminum
CPU: Celeron Processor J6412 1.5M Cache, up to 2.60 GHz
Memory: 1 x SODIMM DDR4 3200 MT/s, MAX. 32GB RAM
Storage: 1 x M.2 2280 M-key PCIE3.0 x1 SATA/NVME SSD, 1 x 2.5 Inch SATA SSD/HDD
Network: 2 x RTL8111H Gigabit LAN
Expansion: Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
WiFi: Wi-Fi 6 802.11AX
Bluetooth: 5.2
Optional Expansion: 936V wide voltage power, GPIO, CAN module, COM etc
I/0 Port: Power Switch, 4 x USB3.0, 4 x COM COM1 COM2 for RS232/485, Audio, 2 x USB2.0, 2 x LAN, 2 x HDMI, VGA, DC_IN
Power Supply: DC100-240V AC/50-60Hz, DC 12V5A
Operating Temperature: -20°C ~ +50°C, surface air flow
Working Humidity: 5%~95% non-condensing
Size: 186 x 127 x 66mm
Weight: 1.36kgs
Consumption: 10W
Cooling system: Fanless
Function: Support Auto power on, Timing boot, Wake on LAN, PXE boot, Watchdog 0255 level, TPM2.0 security encryption
Packing List: ANDAQI IX20 embedded computer, power supply, power cord, WiFi antennas, mount bracket, warranty card
Installation: Supports Desktop, Din Rail, wall-mounted and other fixing methods, default as vesa mount method,
if need Din Rail, please refer to Din Rail type
System Support: Windows 10/11, Linux Ubuntu
System Default Option: Windows 11 pro in English
ATTENTION: Other options, Linux or other system, other system language, do leave ANDAQI message on the order, thank you
