SJRC Industrial Mini PC Core i5-8350U Fanless, DDR4 Barebone NO RAM/SSD/OS, 6 RS232/485 COM, i211/i210 LAN, 6 USB, GPIO, Support Win/Linux, 9-36V 3pin DC
- Industry CPU performance: The fanless computer with Core i5-8350U of the 8th Generation, 4 cores, 8 threads, up to 3.6 GHz, 6 MB cache, 15 W TDP, no operating system by default. Designed for 24/7 automation, edge computing and low-power multitasking
- Expandable DDR4 RAM: Two DDR4 SODIMM slots (up to 32GB), 1x sim card slot, 1x M.2 NVMe 2280 SSD, 1x mSATA, 1x 2.5" SATA HDD/SSD bay for large data storage. Supports hard driveless boot via PXE and watchdog timer for fail-safe operation
- Robust connectivity and expandability: 6x RS-232 COM ports (4 support RS485/RS442), 2 x i211/i210 1GbE LAN, 14-pin GPIO, 4x USB 3.0, 2x USB 2.0, HD+VGA dual display and modular expansion with pre-installed 4G IMIM slot, ideal For PLCs, CNC machines and IoT gateways
- COMPACT & VERSATILE INSTALLATION This compact PC (9.8 x 5.9 x 3.4 inches) supports wall mounting (bracket included) or desktop placement, saving space in control cabinets or server racks, 4.85 pounds. Compatible with Linux, Win 10/11 and indust
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
"Industrial Fanless Mini PC with In-tel Core i5-8350U
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this item
Technical Specifications:
CPU: In-tel Core i5-8350U (4C/8T, 3.6GHz).
System: No OS
Memory: 2x DDR4 SODIMM (32GB Max). Note: It will take 5-10 minutes for the device to detect the RAM for the first time. Please be patient.
Storage: M.2 NVMe 2280 + mSATA + 2.5"" SATA.
Networking: 2x i211/i210 Gbe, dual-band module (2.4G/5G connection).
I/O: 6x RS-232 COM ports (4 support RS485/RS442), 14-pin GPIO, 4x USB 3.0, 2x USB 2.0, HDMl 4K, VGA, PS/2, audio jacks.
Power: 9-36V DC input (3-pin Phoenix terminal).
Dimensions: 9.8"" x 5.9"" x 3.4"" (249x150x86mm).
Weight: 4.85 lbs (2.2kg).
Operating Temperature: -20°C to +60°C.
Storage Temperature: -30°C to +70°C.
Humidity: 10%~90% non-condensing.
Expansion: 1x full-height Mini-PCIe (Support 3G/4G module) with SIM slot, 1x half-height Mini-PCIe.
Why Choose This Industrial PC?
Reliability: Fanless design reduces failure risks in dusty or high-vibration settings.
Scalability: Expand with 4G modules, additional storage, or custom I/O.
Easy Integration: Pre-configured for Win/Linux; UEFI BIOS for quick setup.
Package Includes:
1x Mini PC, 1x power adapter, 1x bracket, 2x antennas, 1x SATA cable.
"
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this item
Technical Specifications:
CPU: In-tel Core i5-8350U (4C/8T, 3.6GHz).
System: No OS
Memory: 2x DDR4 SODIMM (32GB Max). Note: It will take 5-10 minutes for the device to detect the RAM for the first time. Please be patient.
Storage: M.2 NVMe 2280 + mSATA + 2.5"" SATA.
Networking: 2x i211/i210 Gbe, dual-band module (2.4G/5G connection).
I/O: 6x RS-232 COM ports (4 support RS485/RS442), 14-pin GPIO, 4x USB 3.0, 2x USB 2.0, HDMl 4K, VGA, PS/2, audio jacks.
Power: 9-36V DC input (3-pin Phoenix terminal).
Dimensions: 9.8"" x 5.9"" x 3.4"" (249x150x86mm).
Weight: 4.85 lbs (2.2kg).
Operating Temperature: -20°C to +60°C.
Storage Temperature: -30°C to +70°C.
Humidity: 10%~90% non-condensing.
Expansion: 1x full-height Mini-PCIe (Support 3G/4G module) with SIM slot, 1x half-height Mini-PCIe.
Why Choose This Industrial PC?
Reliability: Fanless design reduces failure risks in dusty or high-vibration settings.
Scalability: Expand with 4G modules, additional storage, or custom I/O.
Easy Integration: Pre-configured for Win/Linux; UEFI BIOS for quick setup.
Package Includes:
1x Mini PC, 1x power adapter, 1x bracket, 2x antennas, 1x SATA cable.
"
