Ndarepoo Mini Compact Industrial 8-Port 10/100/1000T 802.3at 30W PoE + 2-Port 100/1000X SFP Din Rail Unmanaged Switch Ethernet Switch IEEE802.3af/at 30W/240W 48-57V DC Input

Overview: The NDE-IMC208SGP-SFP is a versatile Ethernet switch equipped witheight Gigabit Ethernet ports and two SFP fiber ports. It offers PoE+capabilities across all eight RJ45 ports, delivering both power and data to avariety of devices. The two 100/1000Base-X SFP ports support both single-modeand multi-mode fiber connections. With its dependable performance anduser-friendly features, this product is an excellent choice for integrating networks connecting remote devices such as IP cameras and wireless accesspoints.
Features: 1.8 Gigabit Ethernet Ports + 2 SFP Fiber Ports 2. Gigabit RJ45 Ports Support Full/Half-Duplex, Auto-Negotiation, and Auto MDI/MDIX 3. IEEE 802.3 at PoE+ Support (30W per Port) 4.802. 3x Flow Control Supported 5. Compliance with IEEE Ethernet Standards 6. IEEE 802.3 az Energy Efficient Ethernet (EEE) 7. Redundant Power Inputs 8. DIN-Rail Mounting Capability 9.
Wide Temperature Range: -40degC to 80degC (-40degF to 176degF)
Operating Range Specification: Backplane
bandwidth: 20Gbps Packet
Buffer Memory: 9216bits
Processing Type: Store-and-Forward
Max Packet Length: 9K Bytes Jumbo Frame Address Table Size: 4K MAC Addresses
Power Pin Assignment: 4/5(+), 7/8(-) Mode-B
PoE Budget: Up to 240-watt
PoE budget Operating Temperature: -40degC to 80degC (-40degF to 176degF)
Storage Temperature: -40degC to 85degC (-40degF to 185degF)
Input Power: 48~57VDC, Redundant Power (4-pin Terminal Block)
Power Consumption: 5W Max. (PoE in Use<240W)
Power Input Overload: Automatic
Resettable Reverse Polarity: Present
