CWWK Mini PC N Series 8-core N305 Intel Quad Core Fanless Mini Host Soft Route. (Barebone)
- 1*SO-DIMM DDR5 memory 4800MHz compatible with 5200/5600MHZ
- 4*Intel i226-V network card chip full UDE2.5G with filter connector
- HDM12.1+DP1.4 dual display interface, support 4096 x 2160@60Hz
- M.2NVMe x4 high-speed interface, can split multiple M.2 hard drives through the adapter board
- M.2 WiFi slot supports Bluetooth/WiFi6 wireless receiving block;M.2 WiFi interface supports adapter board expansion M.2NVMe or mSATA solid state disk
- The M.2 x4 interface supports the expansion of 2 M.2 NVMe x1 adapter boards
- TF card holder supports data storage or system boot; 2*small 4PIN fan, fan power supply base supports temperature control fan
- If you need to customize the LOGO on the panel, please contact customer service and provide free laser laser engraving (PS: laser-engraved machines do not support returns).
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Processor: Intel i3-N305
Memory: 1* SO-DIM DDR5 480OMHZ (compatible with 5200//5600MH2) as large as 32GB
Storage: 1*M. 2 NVMex4 (multiple M. 2 or mSATA/SATA can be supported through the adapter board)
Graphics: Intel UHD Graphics
Display: HDMI 2.1 supports 4096x2180@60Hz
DP 1.4 supports 4096x2160@60Hz
Network card: 4*intel i226. V 2.5G network card
Wifi: 1*M. 2 KEY E (support Bluetooth/WiFi6 module
USB: 4*USB 2.0
Heat dissipation: no fan, two copper tubes heat conduction aluminum shell passive heat dissipation
BIOS: AMI EFI BIOS supports self-starting when calling, GPIO, PXE network calling super
Power Consumption: 15W
Power supply: DC-12V5 (5*25 connector)
Chassis: aluminum alloy material
Extended pin header: 2*4Pin fan header with temperature control, 1*serial pin header, 1*USB pin header, 1*SW (shutdown USB pin header)
Expandable: M. 2WiF supports expansion to NVMe/SATA/mSATA hard disk signals
M. 2 X4 socket can expand 2/3/4 M. 2x1
Size: 145.6 mm (L) 145.4 mm (W) X 53.6 mm (H)
Color: Grey/Black
Installation method: desktop, wall-mounted (contact customer service for additional purchase)
Working environment: -0degC~t70'C relative temperature 5%-85%
Memory: 1* SO-DIM DDR5 480OMHZ (compatible with 5200//5600MH2) as large as 32GB
Storage: 1*M. 2 NVMex4 (multiple M. 2 or mSATA/SATA can be supported through the adapter board)
Graphics: Intel UHD Graphics
Display: HDMI 2.1 supports 4096x2180@60Hz
DP 1.4 supports 4096x2160@60Hz
Network card: 4*intel i226. V 2.5G network card
Wifi: 1*M. 2 KEY E (support Bluetooth/WiFi6 module
USB: 4*USB 2.0
Heat dissipation: no fan, two copper tubes heat conduction aluminum shell passive heat dissipation
BIOS: AMI EFI BIOS supports self-starting when calling, GPIO, PXE network calling super
Power Consumption: 15W
Power supply: DC-12V5 (5*25 connector)
Chassis: aluminum alloy material
Extended pin header: 2*4Pin fan header with temperature control, 1*serial pin header, 1*USB pin header, 1*SW (shutdown USB pin header)
Expandable: M. 2WiF supports expansion to NVMe/SATA/mSATA hard disk signals
M. 2 X4 socket can expand 2/3/4 M. 2x1
Size: 145.6 mm (L) 145.4 mm (W) X 53.6 mm (H)
Color: Grey/Black
Installation method: desktop, wall-mounted (contact customer service for additional purchase)
Working environment: -0degC~t70'C relative temperature 5%-85%
