Sunhans eSunRC RC Wireless Signal Booster, 2.4GHz and 5.8GHz Dual Band 2000mW 33dBm UAV WiFi Signal Booster Amplifier Repeater Extender Ultralight 2.7oz (77g), for Drones, UAV, RC
- Brand new and High Quality. New design for simple, 2.4G and 5.8G dual band wifi signal booster could Auto switch frequency, 2000mW real output power; 5-16V wide voltage range,support different power supply;Aluminum-alloy case by CNC, anti-interference;Designed for Drones, UAV, RC equipment.
- Small size and Light weight : the WiFi signal booster have the feature of light weight (2.72 OZ) and small size: 3.82 x 2.05 x 0.43 inches, can easy install in DJI drones ,XIRO UAV , RC remote to extend wifi signal range and the flying distance of drones.Simply plug and play, no software is required.
- 2.4Ghz and 5.8Ghz Signal booster coverage range and usage : Drone signal booster output power is 2000mw, transmit gain 15db~18db can greatly improve flying distance 1~2 times. It could install in drones or remote control , through cable one side connect with device, and other side with antenna. Turn on to work, it can boost wifi signal range to extend the flying distance of drones.
- SU
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Features:
New design for simple, simple, simple;
2.4G & 5.8G dual band, Auto switch frequency;
Max. 2000mW real output power;
5-16V wide voltage range, support different power supply;
Aluminum-alloy case by CNC, anti-interference;
Designed for Drones, UAV, RC equipment.
Technical
Booster Model: SH-RC5824G2W
Operating Range: 2.4 ~ 2.5 GHz, 5.0 ~ 5.875 GHz
Operating Mode: Bi-directional, half-duplex, time division duplex senses RF, carrier from transmitter and automatically switch receiving to transmitting mode.
Connector Type: SMA Receptacle 50ohm, To radio SMA female (hole inside), To antenna RP-SMA female (pin inside)
Input Power: 0~20 dBm
Transmit Gain: 15-18dB
Output Power: 2000mW (33dBm)
Receiver Gain: 12 dB
Noise Figure: 3.5 dB typical
Frequency Response: +-1dB over operating range
Supported voltages: 5V~16V/2A DC
Operating Temperature: -20degC to + 70degC
Operating Humidity: Up to 75% relative humidity
Material: Cast Aluminum
Booster Weight: 77g
Booster Size: 9.7 x 5.2 x x 1.1 cm
Package included:
1 x SH-RC5824G2W WiFi booster
1 x DC 2.5" to USB adapter
1 x Mounting Velcro
1 x User Manual
New design for simple, simple, simple;
2.4G & 5.8G dual band, Auto switch frequency;
Max. 2000mW real output power;
5-16V wide voltage range, support different power supply;
Aluminum-alloy case by CNC, anti-interference;
Designed for Drones, UAV, RC equipment.
Technical
Specifications
:Booster Model: SH-RC5824G2W
Operating Range: 2.4 ~ 2.5 GHz, 5.0 ~ 5.875 GHz
Operating Mode: Bi-directional, half-duplex, time division duplex senses RF, carrier from transmitter and automatically switch receiving to transmitting mode.
Connector Type: SMA Receptacle 50ohm, To radio SMA female (hole inside), To antenna RP-SMA female (pin inside)
Input Power: 0~20 dBm
Transmit Gain: 15-18dB
Output Power: 2000mW (33dBm)
Receiver Gain: 12 dB
Noise Figure: 3.5 dB typical
Frequency Response: +-1dB over operating range
Supported voltages: 5V~16V/2A DC
Operating Temperature: -20degC to + 70degC
Operating Humidity: Up to 75% relative humidity
Material: Cast Aluminum
Booster Weight: 77g
Booster Size: 9.7 x 5.2 x x 1.1 cm
Package included:
1 x SH-RC5824G2W WiFi booster
1 x DC 2.5" to USB adapter
1 x Mounting Velcro
1 x User Manual
