For HP 2.5" SSD to 3.5 inch SATA Adapter Tray HDD Brackets Bay 654540-001

For HP 2.5" SSD to 3.5 inch SATA Adapter Tray HDD Brackets Bay 654540-001

with 4 x 2.5" + 4 x 3.5" Drive Screws

Type: Adapter

MPN: 654540-001

Country/Region of Manufacture: United States

UPC: 699950190208

This adapter can convert any 2.5" SAS/SATA/SSD drive to 3.5" form factor.

However, for 2.5" SAS drives, this adapter will change dual port to single port.

This is fine for most applications. But if your application requires dual port, this adapter will not work for you.

And, as always, a SAS controller is required in order to support SAS drives.

A 2.5" SAS drives with this adapter installed will not work on a SATA controller although its connector looks exactly the same as a normal SATA connector

This adapter is compatible with all the 3.5" SAS/SATA drive caddie trays from HP, Dell, IBM, or other manufacturers,

such as HP 651314-001, IBM 69Y5284, or Dell F238F, Dell KG1CH

Description: This adapter can adapts any 2.5" form factor SAS/SATA/SSD Drive to 3.5" form factor drive, without cables or hassles.

Standard position mounting holes on Adapter's bottom and sides, equivalent to those found on a 3.5" hard drive, give you the flexibility to mount it anywhere a 3.5" drive is used.

Adapter's fixed mount connectors are attached to a simple circuit board, assuring solid connections between devices, and the outside connector is positioned to plug into a backplane as the tray is inserted.

Compatible with 3Gb/s and 6Gb/s SAS/SATA/SSD drives.

No loss in data transfer speedsno bridge chip used

Structure -- SECC(Steel Electrogalvanized Cold-rolled Coil) Steel body

What is included:

1 * 2.5" to 3.5" SATA SSD HDD Adapter (654540-001)

4 * 2.5" Drive Screws + 4 * 3.5 " Drive Screws
