Nanopi NEO Core Open Source Developement Starter Kit Allwinner H3 Quad-core Cortex-A7 1.2GHz Single Board Computer with 512MB DDR3 RAM Ethernet GPIO USB Port Support FriendlyWrt Ubuntu Armbian

High PerformanceCPU: Allwinner H3, Quad-core Cortex-A7 Up to 1.2GH z, Memory: 512MB DDR3 RAM 8G eMMC.
OS/Software: U-boot, Ubuntu, Ubuntu-Core, FriendlyWrt, Armbian and etc.. Geek's ChoiceThe NanoPi NEO Core ARM Board has ESD protection for its MicroUSB port and TF card slot. In addition the NEO Core can have an optional onboard eMMC flash which is preferred by industrial customers.. SDK Carrier BoardThe Mini Shield for NanoPi NEO Core/Core2 is a custom SDK carrier board developed for the NanoPi NEO Core and NanoPi NEO Core2. It has Ethernet port, serial debug port, audio, USB port and etc.. Rich interfaces1 x Serial debug port for connecting a serial communication board, 1 x Ethernet port. 2 x USB Host ports. 1 x JMS567 USB to SATA IC and 1 x M. 2 SSD interface for connecting a 2242 SSD. Room for an SPI Flash(SOP8-200mil) is reserved. Users can solder an SPI flash on the board.. Raspberry Pi DimensionThe NanoPi NEO Mini Shield has the same dimension and mounting holes as those of a Raspberry Pi. The whole board can be well fit into a RPi's case.
WIKI"https: //wiki. friendlyelec. com/wiki/index. php/NanoPi_NEO_Core#Get_Started". Any after-sales problems, please contact us by click WayPonDEV store and ask a question or leave the message in our forum by "forum. youyeetoo. com /".
