Sipeed Tang Nano 20K GW2AR-18 FPGA Single Board Computer, Open Source RISCV Linux Retro Game Console, Onboard 64Mbits SDRAM BL616 Debugger, Support Multiple Display Outputs NES Emulator

[FPGA Chip] Sipeed Tang Nano 20K Linux Signle Board Computer with GW2AR-18 QN88 FPGA Chip containing 20736 LUT4 logic cells and 15552 Filp-Flops. There are 2 PLL in this FPGA chip, and many DSP units supporting 18 bit x 18 bit multiplication.. [Onboard Debugger ] Sipeed Tang Nano 20K Signle Board Computer support JTAG for FPGA, USB to UART for FPGA, USB to SPI for FPGA communication, Control MS5351 generate frequency. [USB 2.0 HS interface] The 27MHz crystal generates the clock for HDMI display, onboard MS5351 clock generating chip also provides mutiple clocks.

Support Serial communication, high-speed SPI reception.. [Application scenarios] Tang Nano 20K Open source RISCV Signle Board Computer supports game console emulators, drives RGB screens, multiple display outputs, 20K LUT4, RISC-V soft-core experiments.. [Wiki] "dl. sipeed. com/shareURL/TANG/Nano_20K/1_Datasheet". Any after-Sales Privems, Please Contact us by click "Waypondev" store and ask a question or leave the message in our forum by "forum. youyeetoo. com/".
