Mini High Clarity 1080P HDMI-compatible to AV CVBS/RCA Adapter Converter Audio Video for TV Projector

Package:Yes
Type:USB Adapter
Origin:Mainland China
Certification:NONE
Products Status:STOCK

Mini High Clarity 1080P HDMI-compatible to AV CVBS/RCA Adapter Converter Audio Video for TV Projector
Specification:
This HDMI-compatible to composite A/V converter will provide Y/R/W RCA connection from any HDMI-compatible signal.
It is ideal for feeding set-top boxes or media devices into an existing club or enterprise A/V distribution system.
The item is also useful for situations where you already have A/V cable and do not need to upgrade to A full HDMI-compatible signal.
The product is widely used in home display, high clarity LCD TV sales display venues, HDTV, STB and DVD production testing, as well as data release, information release, conference rooms, schools and various training venues, etc.
It has automatic detection signal function, and can according to the input signal automatically adjust the output signal standard.
It converts HDMI-compatible high clarity signals to 576I and 480I(PAL/NTSC) video signal output
The item automatically identify HDCP and forcibly remove the KEY(HDCP) attached to the front-end HDMI-compatible.
It converts HDMI-compatible digital audio into audio analog stereo after DAC digital analog chip processing.
Adopted 3D compensation technology, it can effectively eliminate the shake and drag of the fast moving screen.
Using DAC technology, it converted HDMI-compatible digital audio signal into analog audio through the DAC digital analog chip.
Type: Adapter
Material: Metal
Plug Type: US Plug
Input Port: 1 x HDMI-compatible
Output Port: 1 x AV CVBS/RCA
Input HDMI-compatible Signal Format: 480p(60Hz), 576P(50Hz), 720p(50Hz/60Hz), 1080i(50Hz/60Hz), 1080p(50Hz/60Hz)
Output Signal: CVBS(1.0Vpp)
Output Video Format: PAL, NTSC
Impedance Matching of Output Video Signal: 75 Ohms
Support: HDCP Protocol
Power Supply: DC 5V
Working Environment Temperature: -45-75 Degree Celsius
Humidity of Working Environment: 10-60 Percent
Features: Compact, HDMI-compatible Input, Plug and Play
Size: 8cm x 5.5cm x 2.2cm/3.15" x 2.17" x 0.87" (Approx.)
Notes:
Due to the light and screen setting difference, the item's color may be slightly different from the pictures.
Please allow slight dimension difference due to different manual measurement.
Package Includes:
1 x Adapter
1 x User Manual
1 x USB Charging Cable
1 x US Plug Power Supply
