Mean Well WDR-60-12 Single Output Industrial Power Supply 60W 12V - DIN Rail

FeaturesSingle and two phase wide input range 180~550VACProtections: Short circuit / Overload / Over voltage / Over temperatureCooling by free air convectionBuilt-in constant current limiting circuitCan be installed on DIN rail TS-35 / 7.5 or 154.7KVac I/O high isolation(Reinforced isolation)Over voltage category IIIBuilt-in DC OK relay contactDC output voltage adjustable(+20%)3 years warranty
General Specification AC input voltage range180~550VAC(single and two phase); 254~780VDCAC input current0.4A / 400VAC, 0.7A / 230VACAC inrush current (max.)Cold start, 50A at 400VACDC adjustment range5V: 5-6V, 12V: 12~15V, 24V: 24~29V, 48V: 48~57VOverload protection105%~130% rated output power, constant current limiting, auto-recoveryOver voltage protection Range6.2~7.2V for 5V model, 16~18V for 12V model, 31~37V for 24V model, 58~60.5V for 48V modelOver voltage protection TypeShut down o/p voltage, auto-recoverySetup, rise, hold up time2000ms, 70ms, 10ms at full load and 230VAC; 1000ms, 70ms, 20ms at full load and 400VACOver temp. protectionShut down output voltage, recovers automatically after temperature goes downWithstand voltageI/P-O/P:4.7VAC, I/P-FG:2.5kVAC, O/P-FG:0.5kVAC, O/P-DC OK:0.5kVACWorking temperature-40~+85°C DC OK signalRelay ContactLeakage current<2mA at 530VACVibration10~500Hz, 2G 10 minutes / 1 cycle, period of 60 minutes each along X, Y, Z axesSafety standardsUL61010 approved ; AS/NZS 62368.1EMC standardsEN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2, EN61204-3ConnectionI/P: 3 poles, O/P: 4 poles screw DIN terminalDimension (LxWxH)32x125.2x102Packing28pcs / 13.6kg
