Meanwell RSP-500-4 Power Supply - 360W 4V 90A - Low Profile

Features:
1U low profile
Universal AC input / Full range
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
LED indicator for power on
3 years warranty
General Specification (Please refer to images below for detailed datasheet)
AC input voltage range:85~264VAC; 124~370VDC
AC inrush current (max.):Cold start, 40A at 230VAC
DC adjustment range:±10% rated output voltage
Overload protection Range:105%~130%
Overload protection Type:Constant current limiting, auto-recovery
Over voltage protection Range:115%~145%
Over voltage protection Type:Shut down O/P voltage, re-power on to recover
Withstand voltage:I/P-O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature:-30~+70°C (refer to output derating curve)
Safety standards:UL60950-1, TUV EN60950-1 (TUV / UL pending for RSP-500)
EMC standards:EN55022 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61000-6-2
Connection Input:3P / 9.5mm pitch terminal block
Connection Output:6P / 11mm pitch terminal block
Dimension (LxWxH):230x127x40.5
Case No.:226A
