Features
Constant current mode (HBG-60/100) Constant voltage+constant current modes (HBG-160/240)
Universal AC input (up to 305VAC)/ Full range (up to 295VAC for HBG-60)
High efficiency up to 93.5%
Patented metal housing design for HBG-100/160/240 (Patent No.: CN201220314551) Fully isolated plastic case (HBG-60)
Type HL LED Driver for use in Class I, Division 2 hazardous location luminaires (HBG-100/160)
Isolation class II, no F.G. (HBG-60)
Class 2 power unit (HBG-60) HBG-60 HBG-100 HBG-160 HBG-240
Suitable for dry, damp, and wet location
Protections: Short circuit / Over current / Over voltage / Over temp. (Short circuit / Over temp. for HBG-60)
Multiple models for HBG-100/160/240 A-Type: IP65 rated. Constant current level can be adjusted through internal potentiometer B-Type: IP67 rated and built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance) Blank Type: IP67 rated. Cable for I/O connection
Optional CCC (100~240W) & RCM models available
5 years warranty
