Mean Well EPP-200-48 201.6W Single Output with PFC Function EPP-200 48V 4.2A
- 4"x2"miniature size
- Universal AC input / Full range
- Built-in active PFC function
- EMI Conduction for Class B Radiation for Class B with FG(Class I ) and Class A without FG(ClassII)
- No load power consumption<0.5W
- High efficiency up to 94%
- Protections: Short circuit / Overload / Over voltage /Over temperature
- Cooling by free air convection for 140W and 200W with 10CFM forced air
- Built-in 12V/0.5A FAN supply
- LED indicator for power on
+
+
Overview
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
EPP-200 is a 20oW highly reliable green PCB type power supply with a high power density (21.9Wrin) onthe 4" by 2 footprint. It accepts 80~264VAC input and offers various output voltages between 12V and 48V. The working efficiency is up to g 4%t and tns Ix(twrith FG)and Class Il(no FG) systerm design.EPnS 3po iasEPP-200 is able to be used for both Class (with FG) and Class Il(no FG) system design.EPP-200 is equipped with complete protection functions; it is complied with the international safety regulations such asTUV BS EN/EN62368-1,UL62368-1 and lEC62368-1.EPP-200 series serves as a high price-to-performancepower supply solution for various industrial applications.
