MEAN WELL RSD-60H-24 24V 2.5A 60W Reliable Railway Enclosed DC-DC Converter 40-160 Vin
- Number of Outputs: 1
- Output Voltage: 24 VDC
- Additional Output Voltages (VDC): N/A
- Output Current: 2.50 A
- Input Voltage Range: 40 VDC to 160 VDC
+
+
Overview
Reviews
24V 2.5A 60W Reliable Railway Enclosed DC-DC Converter 40-160 Vin24 Volts DC @ 2.5 AmpsFeatures --Compliance to EN50155 and EN45545-2 railway standard--Ultra compact and 1U low profile (25mm)--4:1 wide input range--No minimum load required--Protections: Short circuit, overload, over voltage, input reverse polarity--4000 VDC I/O isolation--Half encapsulated, cooling by free air convection---40 to +70°C wide working temperature--Built-in constant current limiting circuit--LED indicator for power on--Screw terminals--3 year warranty Specifications --Output voltage: 24 VDC--Output current: 2.5 Amps--Rated power: 60 Watts--Input voltage range: 40 to 160 VDC--Efficiency: 91.5%--Line regulation: 0.2%--Load regulation: 0.2%--Ripple & noise: 50 mVp-p--Size: 5.04"L x 2.36"W x 0.98"H--Agency approvals: CE Applications --Bus, tram, metro or railway systems--Highly vibrating, highly dusty, extremely low or high temperature harsh environment--Wireless network--Telecom or Datacom system--Industry control system
