Meanwell LRS-350-24 350W 24VDC 14.6A 115/230VAC Enclosed Switching Power Supply Switching Converter LED Driver for LED Strip Light CCTV Camera Security System, Computer Project,3D Printer
- Output Voltage(VDC): 24
- Power(W): 350.4
- Max. Output Current(A): 14.6
- Input Voltage(VAC/VDC): 90 - 132 / 180 - 264
- Dim.(LxWxH)(mm): 215 x 115 x 30 / 8.46 x 4.53 x 1.18
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
LRS-350 series is a 350W single-output enclosed type power supply with 30mm of low profile design. Adopting the input of 115VAC or 230VAC (select by switch), the entire series provides an output voltage line of 3.3V, 4.2V, 5V, 12V, 15V, 24V, 36V and 48V. In addition to the high efficiency up to 89%, with the built-in long life fan LRS-350 can work under -25~ +70 with full load. Delivering an extremely low no load power consumption (less than 0.75W), it allows the end system to easily meet the worldwide energy requirement.LRS-350 has the complete protection functions and 5G anti-vibration capability; it is complied with the international safety regulations such as IEC / UL 62368-1. LRS-350 series serves as a high price-to-performance power supply solution for various industrial applications.
Features
24V DC 14.6A output
AC input voltage range: 90 ~ 132VAC
Rated power: 350.4W
AC input range selectable by switch
Withstand 300VAC surge input for 5 second
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
Built-in cooling Fan ON-OFF control
1U low profile
Withstand 5G vibration test
LED indicator for power on
No load power consumption<0.75W
100% full load burn-in test
High operating temperature up to 70
Operating altitude up to 5000 meters (Note.8)
High efficiency, long life and high reliability
3 years warranty
Applications
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
Features
24V DC 14.6A output
AC input voltage range: 90 ~ 132VAC
Rated power: 350.4W
AC input range selectable by switch
Withstand 300VAC surge input for 5 second
Protections: Short circuit / Overload / Over voltage / Over temperature
Forced air cooling by built-in DC fan
Built-in cooling Fan ON-OFF control
1U low profile
Withstand 5G vibration test
LED indicator for power on
No load power consumption<0.75W
100% full load burn-in test
High operating temperature up to 70
Operating altitude up to 5000 meters (Note.8)
High efficiency, long life and high reliability
3 years warranty
Applications
Industrial automation machinery
Industrial control system
Mechanical and electrical equipment
Electronic instruments, equipments or apparatus
