Switching Power Supply Single Output Switching Power Supply 350w 48V 7.3A for Machine DIY, Input 220v/110v
- IN-DOOR USE ONLY!
- Circuit Short Protection, Overload Protection and Over Voltage Protection Ensures the Safety of Using This Power Supply
- Metal Enclosed Body is good for Heat Dissipation which Can Prolong the Lifespan of the Power Supply
- Stable Performance -The DC ripple is small, the power supply efficiency is high, and the electromagnetic interference is low, long service life.
- Wide Application - The dc 24v power supply is widely used in industrial automation, led strip light, led lighting, led display, electronic equipment, home appliance etc.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Switching power supply
output power:350w
output: 48VDC, 0~7.3A
Feature&Advantages
Universal AC input by witch
ProtectionsShort circuit /Over load
Forced air cooling by built -in DC fan
Low cost ,high reliability
Input voltage: 85~264VAC, 47~63HZ;
AC inrush current : Cold stat ,15A/115VAC 30A/230vac
Dcadjustment range : ±10%
Over load protection :105% ~150%fold back current limiting ,auto-recovery
Over voltage protection :115%~135% fold back current limitting, auto-recovery
Setup,rise,hold uo time:200ms ,80ms,20ms at full load and 230vac
Withstand voltage:i/p-o/p:1.5KVAC,I/P-FG:0.5kVAC 1minute
Working tempure:-10°C~+60°C2, 0%~90%RH(5~7.5V,0-45°C)
Safety standars:Design refer to UI1012
EMC standards:Design refer to FCC part 15
Connection:7p /9.5mm pitch terminal block
Packing :1.2kg; 18pcs/21.0kg/1.2CUFT
Product size : 215/115/50MM
output power:350w
output: 48VDC, 0~7.3A
Feature&Advantages
Universal AC input by witch
ProtectionsShort circuit /Over load
Forced air cooling by built -in DC fan
Low cost ,high reliability
Input voltage: 85~264VAC, 47~63HZ;
AC inrush current : Cold stat ,15A/115VAC 30A/230vac
Dcadjustment range : ±10%
Over load protection :105% ~150%fold back current limiting ,auto-recovery
Over voltage protection :115%~135% fold back current limitting, auto-recovery
Setup,rise,hold uo time:200ms ,80ms,20ms at full load and 230vac
Withstand voltage:i/p-o/p:1.5KVAC,I/P-FG:0.5kVAC 1minute
Working tempure:-10°C~+60°C2, 0%~90%RH(5~7.5V,0-45°C)
Safety standars:Design refer to UI1012
EMC standards:Design refer to FCC part 15
Connection:7p /9.5mm pitch terminal block
Packing :1.2kg; 18pcs/21.0kg/1.2CUFT
Product size : 215/115/50MM
