Kulon Mean Well Original LRS-50-12 12V 4.2A meanwell LRS-50 12V 50.4W Single Output Switching Power Supply
- The height is only 30mm, the performance of the high-end model, the price of the economy, high efficiencylong life and reliability ,the quality assurance for three years.
- Protection Short cirsuit/ Overload/ Over voltage ;cooling by free air convection;High operating temperature up to 70.
- 100% original,We can check the serial number on the meanwell website.
- Compliance to IEC/EN60335-1(PD3) and IEC/EN61558-1.-2-16 for household applicaces
- The application fields include industrial automation equipment, industrial control system, mechanical and electrical equipment, electronic instrument and equipment, appliance application and so on.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Product Details: Brand Name:Mean Well
Model Number:LRS-50-12
Output Power:50W
Output Type:Single
Input Voltage:85-264V AC 120-373VDC
Output Frequency:0
Output Current:0~4.2A
Product Name:MEANWELL Single LRS-50-12 dc output 12V computer power supply
Certification:CCC TUV CB EMC CE
Feature:Low profile, small size
Dimension:99*82*30mm (L*W*H) Efficiency:80%
Type:Single
Warranty:3 Years
Working Humidity:20 ~ 90% RH non-condensing
Protection:OVER LOAD/OVER VOLTAGE
Main Features: ·Universal AC input / Full range
·Withstand 300VAC surge input for 5 second
·No load power consumption<0.2W
·Miniature size and 1U low profile
·High operating temperature up to 70
·Protections: Short circuit / Overload / Over voltage
·Cooling by free air convection
·Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1, -2-16 for household appliances
·Operating altitude up to 5000 meters (Note.8)
·Withstand 5G vibration test
·High efficiency, long life and high reliability
·LED indicator for power on
·Over voltage category
·100% full load burn-in test
·3 years warranty
Applications: ·Industrial automation machinery
·Industrial control system
·Mechanical and electrical equipment
·Electronic instruments, equipments or apparatus
·Household appliances
Model Number:LRS-50-12
Output Power:50W
Output Type:Single
Input Voltage:85-264V AC 120-373VDC
Output Frequency:0
Output Current:0~4.2A
Product Name:MEANWELL Single LRS-50-12 dc output 12V computer power supply
Certification:CCC TUV CB EMC CE
Feature:Low profile, small size
Dimension:99*82*30mm (L*W*H) Efficiency:80%
Type:Single
Warranty:3 Years
Working Humidity:20 ~ 90% RH non-condensing
Protection:OVER LOAD/OVER VOLTAGE
Main Features: ·Universal AC input / Full range
·Withstand 300VAC surge input for 5 second
·No load power consumption<0.2W
·Miniature size and 1U low profile
·High operating temperature up to 70
·Protections: Short circuit / Overload / Over voltage
·Cooling by free air convection
·Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1, -2-16 for household appliances
·Operating altitude up to 5000 meters (Note.8)
·Withstand 5G vibration test
·High efficiency, long life and high reliability
·LED indicator for power on
·Over voltage category
·100% full load burn-in test
·3 years warranty
Applications: ·Industrial automation machinery
·Industrial control system
·Mechanical and electrical equipment
·Electronic instruments, equipments or apparatus
·Household appliances
