Kulon Mean Well APV-12-15 LED Power Supplies, Output: 12W 15V 0.8A Constant V LED PS, Input: 90-264VAC; 127-370VDC.
- IP42 waterproof grade, suitable for indoor LED lighting or LED electronic billboard application
- 100% original,We can check the serial number on the meanwell website.
- We don't believe in cheap and cheerful.Reasonable price to ensure quality and service. Buy it now,save time,save life.
- Constant current operation modeClass 2 power supply unitClass 2 power supply unit
- Lead free process, in line with the requirements of environmental protection RoHS
+
+
Overview
Reviews
Product Details: Brand Name:Mean Well
Model Number:APV-12-15
Output Power:12W
Output Type:Single
Input Voltage:90 ~ 264VAC 127 ~ 370VDC
Output Voltage:12V
Output Frequency:0Hz
Output Current:0~1A
Power supply:AC-DC switching power
Demension:77*40*29mm (L*W*H)
0.2A/230VAC 0.35A/115VAC:AC CURRENT
COLD START 35A/115VAC 70A/230VAC:INRUSH CURRENT(max.)
OVER VOLTAGE:Protection type : Shut off o/p voltage, clamping by zener diode
WITHSTAND VOLTAGE:I/P-O/P:3.75KVAC
WORKING TEMP.:-30 ~ +70°C (Refer to "Derating Curve")
VOLTAGE RANGE Note.4:90 ~ 264VAC 127 ~ 370VDC
Color:White
Main Features: Constant voltage design
Universal AC input / Full range
Protections: Short circuit / Over load / Over voltage
Fully isolated plastic case
Cooling by free air convection
Small and compact size
Class power unit, no FG
Class 2 power unit
Pass LPS
IP42 design
Suitable for LED related fixture or appliance
(such as LED Decoration or Advertisement devices}
100% full load burn-in test
Low cost, high reliability
2 years warranty
IS 15885(Part 2/Sec13)
Model Number:APV-12-15
Output Power:12W
Output Type:Single
Input Voltage:90 ~ 264VAC 127 ~ 370VDC
Output Voltage:12V
Output Frequency:0Hz
Output Current:0~1A
Power supply:AC-DC switching power
Demension:77*40*29mm (L*W*H)
0.2A/230VAC 0.35A/115VAC:AC CURRENT
COLD START 35A/115VAC 70A/230VAC:INRUSH CURRENT(max.)
OVER VOLTAGE:Protection type : Shut off o/p voltage, clamping by zener diode
WITHSTAND VOLTAGE:I/P-O/P:3.75KVAC
WORKING TEMP.:-30 ~ +70°C (Refer to "Derating Curve")
VOLTAGE RANGE Note.4:90 ~ 264VAC 127 ~ 370VDC
Color:White
Main Features: Constant voltage design
Universal AC input / Full range
Protections: Short circuit / Over load / Over voltage
Fully isolated plastic case
Cooling by free air convection
Small and compact size
Class power unit, no FG
Class 2 power unit
Pass LPS
IP42 design
Suitable for LED related fixture or appliance
(such as LED Decoration or Advertisement devices}
100% full load burn-in test
Low cost, high reliability
2 years warranty
IS 15885(Part 2/Sec13)
