$659.99
Meet Your Seller
Allen Bradley 1762-OW16 / B MicroLogix 16 Point Relay Output Module Factory Sealed
- Brand Allen-Bradley / Rockwell Automation
- Series 1762 MicroLogix AC/DC normally open relay output module
- Part Number 1762-OW16
- Series: MicroLogix 1200
- UPC: 10611320152149
- Number of outputs 16
- Operating voltage range 5265V AC, 5125V DC
- Current draw at 5.1V / 24V 120 mA / 140 mA
- Heat dissipation 5.6 W
- Current per module, max 16 A
- Wire size and type 0.325 2.080 mm2 (2214 AWG) solid copper wire or 0.3251.310 mm2 (2216 AWG) stranded copper wire rated at 90 °C (194 °F ) insulation max
- Current per point 2.5 A
- Operating temperature range 0 degrees to 55 degrees Celsius (32 degrees to 131 degrees Fahrenheit)
- Dimensions (H x W x D), approx 90 mm (H) x 87 mm (D) x 40.4 mm (W) (3.54 in. (H) x 3.43 in. (D) x 1.59 in. (W))
- Weight 285 grams (0.63 pounds)
- Module location DIN rail or panel mount
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Designed and produced by the company known as Allen Bradley / Rockwell Automation, part number 1762-OW16 is a MicroLogix relay output module. This module has sixteen (16) outputs. The operating voltage range of this device is 5 to 265 volts AC or 5 to 125 volts DC. The heat dissipation rating of this module is 6.1 watts. This module has an IP20 rated enclosure. The physical dimensions of this module measure 90 mm x 40.4 mm x 87 mm.
