CNLINKO Outdoor Lighting Electrical Cable Power connectors, pin Socket Plug Connector Waterproof M16 4PIN, Male to Female Panel Mount Connector (4 PIN)

LP-16-C04PE-01-001 + LP-16-J04SX-03-401; Male Plug + Female Socket;
Connecting Mode: Plug/Unplug; Protection Level: IP67 (Mated);
Standard Cable Specification: 1.0 - 1.5 mm²/18-16AWG;
Cable Diameter Range: 3.0 ~ 8.5 mm; Contact Diameter ×
Number: 1.5 x4;
Durability: 500 Mating/Unmating Cycle;
Temperature Rating: -40°C ~ 80°C; Assembly Style: Solder;

Specifications

Rated Current: 10A; Operating Voltage (AC.
V. rms): 400V; Withstanding Voltage (AC. V), 1
Minute: 1500V;
Contact Resistance: <3.0m; Insulation Resistance: 500M; Prohibited To Charged Inserted;
Material Shell & Insulated Parts: Metal & High Performance Engineer Plastic;
Hard Metal: Zinc Alloy (Pearl Hard Chromium);
Contact: Copper Alloy (Gold Plated);
Sealing: Silica Gel;
Application Medical Equipment; Server; Electric Power Equipment; Solar Energy Equipment; The Smart Grid; Communications Equipment; Vehicle Equipment; Ship Equipment; Stage Equipment; Heavy Machin;
