1000w Switching Power Supply AC-DC Output 0-12v 13.8v 15v 24v 36v 48v 60v 72v 90V 110V 220V Voltage and Current Adjustable PSU(220V,0-80V 0-12.5A)

Industrial Power Supply
1000w switching power supply AC-DC output 0-12v 13.8v 15v 24v 27v 36v 48v 60v 72v current and voltage adjustable smp
Constant voltage and constant current are adjustable
External control equipment can be connected.
105 output capacitor
High efficiency, low operating temperature
Soft-start current can effectively reduce AC input impact
With short circuit and overload protection function
Compact size and light weight
100% full load aging test
Install filter, minimum wave
Model specifications
S-1000-12
S-1000-13.5
S-1000-15
S-1000-24
S-1000-27
S-1000-48
DC output voltage (V)
12
13.5
15
twenty four
27
48
DC voltage adjustable range
0-12V
0-13.5V
0-15V
0-24V
0-27V
0-48V
Rated output current (A)
83
74
66.66
41.66
37
20.83
Output current range(A)
0~83
0~110
0~66.66
0~41.66
0~37
0~20.83
Waveform and Noise (mVp-p)
200
200
200
200
200
200
Inlet stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
Load stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
DC output power(W)
1000
1000
1000
1000
1000
1000
efficiency(%)
84
84
85
85.5
86.5
87
AC input voltage range
200~240VAC47~63Hz (220VAC or 110VAC)
Input current
7A/230V
AC surge current
50A/230V
Leakage current
<;3.5mA/240VAC
Overload protection
105%-150%
Overvoltage protection
13.8~16.2V
15.5~18.2V
18~21V
27.6~32.4v
31~36.5V
57.6~67.2V
High temperature protection
70°C cut-off output (0~50°C)
temperature coefficient
±0.03%/(0~50)
Setup time, rise time, hold time
1.5 seconds, 50 milliseconds, 20 milliseconds
vibration
10~500Hz, 2G10min,/1cycle. Cycle 60min, each axis
Pressure resistant
I/PO/P:1.5KVAC
