Adjustable 2000W Switching Power Supply 0-12V 15V 24V 27V 36V 48V 60V 72V 110V 220v 300V 400VDC Power Supply 110/220VAC Input(220V,0-80A 0-25A)

Industrial Power Suppl
Adjustable 2000W switching power supply 0-12V 15V 24V 27V 36V 48V 60V 72V 110V 220v 300V 400VDC power supply 110/220VAC input
105C output capacitor
AC input
Soft-start current can effectively reduce AC input impact
With short circuit and overload protection function
Compact size and light weight
100% full load aging test
Install filter, minimum wave
S2000-12
S-2000-15
S-2000-24
S-2000-27
S-2000-36
S-2000-48
DC output voltage (V)
0-12
0-15
0-24
0-27
0-36
0-48
Output voltage range
±1%
±1%
±1%
±1%
±1%
±1%
Rated output current (A)
160
133
88
74
55.5
41.6
Output current range(A)
0~165
0~133
0~88
0~74
0~55.5
0~41.6
Waveform and Noise (mVp-p)
200
200
200
200
200
200
Inlet stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
Load stability(%)
±0.5
±0.5
±0.5
±0.5
±0.5
±0.5
DC output power(W)
1440
1800
2000
2000
2000
2000
efficiency(%)
84
85
85.5
86.5
86.5
87
DC voltage adjustable range
0-12V
0-15V
0-24V
0-27V
0-36V
0-48V
AC input voltage range
90~130VAC/190~240VAC47~63Hz
Input current
12A/230V
AC surge current
50A/230V
Leakage current
<;3.5mA/240VAC
Overload protection
105%-150%
Overvoltage protection
13.8~16.2V
15.5~18.2V
18~21V
27.6~32.4v
38~54V
57.6~67.2V
High temperature protection
70°C cut-off output (0~50°C)
temperature coefficient
±0.03%/(0~50)
Setup time, rise time, hold time
1.5 seconds, 50 milliseconds, 20 milliseconds
vibration
10~500Hz, 2G10min,/1cycle. Cycle 60min, each axis
Pressure resistant
I/PO/P:1.5KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC
Isolation resistor
I/PO/P,I/P-FG,O/P-FG:100MOs/500VDC
Operatin
