Simple Operation AC/DC 24V 10A Dual Output Power Supply Rail Voltage Lighting Transformer LED Strip Power Supply Drive

Type: AC / DC power supply
Modulation: Pulse width modulation (PWM) type
Transistor connections: single-ended
Input voltage: 88 ~ 132 VAC / 176 ~ 264VAC47 ~ 63 Hz; selected by a switch 248 ~ 370VDC (V)
Output power: 240 (W)
Output voltage: DC: 24 (V)
Efficiency: 80 (%)
Output ripple and noise: 80mVp-p
Output voltage accuracy: ¡À 1% (%)
Voltage Regulation: ¡À 1% (%)

Features: high efficiency, high reliability, low cost
Suitable for universal AC input power supply
100% full load burn-in test
Protection: Short circuit protection / overload / overvoltage
PWM control and mediation
Built-in DC fan forced air cooling
Built-in fan control switch
Operating frequency: 25KHz of
Dimensions: 125.5 * 125.5 * 100 mm (L * W * H)
Weight: 1200g
