CNLINKO Outdoor Lighting Electrical Cable Power connectors, pin Socket Plug Connector Waterproof M16 4PIN, Male to Female Panel Mount Connector (4 PIN)

LP16 4-Pin
Connector Overview: This male plug and four-hole socket combination are designed for plug/unplug connections with an IP68 waterproof protection rating (when mated), ensuring excellent dust and water resistance.
Cable Specification: Designed to fit cables with a size range of 1.0 - 1.5 mm² (18-16 AWG), and a cable diameter of 7.0 ~ 9.0 mm, making it suitable for various industrial and commercial uses. The contact diameter is 1.5 x4. The connector is designed for over 500 cycles at temperatures ranging from -25°C to 85°C.
Electrical

Specifications

: Rated for 10A current and 400V AC operating voltage. With a withstand voltage of 2000V for 1 minute, contact resistance under 3.0 m, and insulation resistance over 500M, ensuring reliable and stable electrical performance.
Note: Avoid charging during insertion.
Materials: Constructed with high-performance engineering plastic for the shell, zinc alloy (pearl hard chromium) for metal components, and gold-plated copper alloy for the contacts. Silica gel sealing provides superior protection against moisture, dust, and corrosion, ensuring long-term durability.
Industrial & Professional Applications: Commonly used in applications like medical equipment, solar energy systems, vehicle electronics, communication devices, and other industrial equipment, providing versatile solutions for professional needs.
