DDR-120D-24 120W DIN Rail Type DC-DC Converter DDR-120D 24V/5A
Limited time offer, ends 07/23 By NaisTechnology
- Compliance to BS EN/EN50155 and BS EN/EN45545-2 railway standard; Width only 32mm; 2:1 wide input range; -40~+70 wide working temperature; 150% peak load capability; DC output adjustable; Cooling by free air convection; Can be installed on DIN rail TS-35/7.5 or 15; Protections: Short circuit / Overload / Over voltage / lnput reverse polarity / Input under voltage protection; 4KVdc l/O isolation(Reinforced isolation)
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
DDR-120 series is a DIN Rail type DC-DC converter with main features including DlN rail-type easy installatiorultra slim width (32mm), 2:1 wide input voltage, fanless design, -40~+70 wide operating temperature, 4KVdcIo isolation, 150% peak load, adjustable output voltage and full protective functions. This series of models has various input options: 9~18V/ 16.8 ~ 33.6V / 33.6 ~ 67.2V / 67.2 ~154V and variousoutput options: 12V/24V/48V and can be used for industrial & railway control, security control, communicationsystem and other fields. Suitable applications include DC buck/boost regulator, increasing system insulation leveand voltage drop compensation along cable... etc.
