4K60 HDMI Encoder with Loopout - 1080P@60fps H.265/H.264 Video Streamer - Supports SRT, RTMP, RTSP, WebRTC, GB28181 - OSD Overlay for Live Streaming, Security
- -4K60 Signal Input & Loopout: Supports up to 4K@60Hz HDMI video input with a pass-through HDMI loopout for real-time local display monitoring.
- -1080P@60fps Stream Encoding: Encodes video output up to 1080p at 60fps using standard H.265 or H.264 video compression and AAC audio compression.
- -Broad Protocol Compatibility: Supports mainstream streaming and networking protocols including SRT, RTSP, RTMP, RTMPS, UDP-TS, HLS, WebRTC, ONVIF, and GB28181.
- -Audio Input/Output & RTMP Decoding: Equipped with 3.5mm stereo analog audio in/out alongside HDMI embedded audio; supports AAC audio decoding via RTMP protocol.
- -OSD Overlay: Custom OSD overlays including PNG graphics, scrolling text.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Product Description
The XSWEDR-SLHDMI-LC-E11 is a single-channel 4K60 HDMI encoder designed for professional audio-visual applications requiring high-quality video streaming and reliable signal management. This device supports HDMI input up to 4K@60 resolution, with a convenient HDMI loopout for real-time video monitoring. It offers flexible audio options, including stereo analog input/output and embedded HDMI audio, with AAC decoding via RTMP protocol. Advanced video encoding supports both H.264 and H.265 formats at up to 1080p60, ensuring efficient streaming across a wide range of network protocols such as SRT, RTSP, RTMP, HLS, and WebRTC. Additional features include PNG/GIF/text overlay, vertical screen rotation, remote management, and a robust metal housing. Ideal for live broadcasting, surveillance, and professional AV integration.
Features
-4K60 Signal Input & Loopout: Supports up to 4K@60Hz HDMI video input with a pass-through HDMI loopout for real-time local display monitoring.
-1080P@60fps Stream Encoding: Encodes video output up to 1080p at 60fps using standard H.265 or H.264 video compression and AAC audio compression.
-Broad Protocol Compatibility: Supports mainstream streaming and networking protocols including SRT, RTSP, RTMP, RTMPS, UDP-TS, HLS, WebRTC, ONVIF, and GB28181.
-Audio Input/Output & RTMP Decoding: Equipped with 3.5mm stereo analog audio in/out alongside HDMI embedded audio; supports AAC audio decoding via RTMP protocol.
-OSD Overlay: Custom OSD overlays including PNG graphics, scrolling text.
| Model | XSWEDR-SLHDMI-LC-E11 |
| Video Input | 1-CH HDMI (Max Resolution: 4K@60Hz |
| Video Output / Loop-out | 1-CH HDMI (Identical to Video Input, 4K@60Hz) |
| Video Encoding Capacity | Up to 1920x1080p@60fps |
| Video Compression | H.265 / H.264 (HEVC / AVC) |
| Output audio encoding format | AAC |
| Audio Input | 1-CH 3.5mm Stereo Analog Audio / HDMI Embedded Audio |
| Audio Output / Decoding | 1-CH 3.5mm Stereo Audio (Supports RTMP Audio Stream Decoding) |
| Audio encoding bit rate | 8Kbit/s ~ 256Kbit/s |
| Video encoding bit rate | 35Kbps~6Mbps |
| Network Interface | 100M Ethernet Port |
| Streaming Protocols | SRT, WebRTC, RTMP, RTMPS, RTSP, UDP-TS, HLS, HTTP_TS, GB28181, ONVIF |
| Special Features | OSD Scroll Text, PNG Overlay, Remote Web Control |
| Dimensions | 150x100x35mm |
| Weight | 333g |
