Note:
- This antenna with SMA MALE Plug connector (Thread inside WITH Pin).
- It only match SMA Female connector (Thread outside WITHOUT Pin)
- Specifications:
- Antenna Connector: SMA Male Connector
- Gain: 3dBi
- Frequency Range: Dual Band WiFi 2.4GHz 5.8GHz
- VSWR: < 2.0
- Polarization: Linear Vertical
- Impedance: 50 ohm
- Direction: Omni-directional
- Connector: SMA Male Connector
- Net Weight: 68g
- Operating Temperature: -20°C ~ +80°C
- Storage Temperature: -30°C ~ +85°C
- Package List: 2 x WiFi Antennas
Dual Band WiFi: 2.4GH z (2400 - 2485 MHz), 5GHz/ 5.8GH z (5150 - 5850 MHz)
Package list: 2 x SMA Male Antennas
Compatible with: WiFi IP Security Camera; Wireless Video Surveillance DVR Recorder; Truck RV Van Trail Rear View Camera, Reverse Camera, Backup Camera, Industrial Router IoT Gateway Modem, M2M Terminal, Remote Monitoring and Control, Wireless Video, Wireless HDMI Extender;
Compatible with: 5GHz 5.8GH z FPV Camera Monitor, FPV Drone Racing Quadcopeter Controller; 5GHz 5.8GH z Wireless AV Video Audio Receiver HDMI Extender;
Tips: It can be used as a 2.4GH z Bluetooth Antenna for Bluetooth Adapter, Bluetooth Audio HiFi Speaker Music System.
