shenzhen 1000M fiber switch 8 port 20KM ftth olt mikrotik MEDIA CONVERTER ethernet switch gigabit switch network switch

shenzhen 10/100/1000M fiber switch 20KM ftth olt mikrotik MEDIA CONVERTER ethernet switch gigabit switch network switch 1000mbps    fibra óptica

Specification:

Standards

IEEE802.3 10Base-T

IEEE802.3u 100Base-TX/FX

IEEE802.3ab 1000Base-T

IEEE802.3z 1000Base-SX/LX

IEEE802.3x Flow control

IEEE802.1p QoS

IEEE802.1d Spanning Tree

IEEE802.1q VLAN

Certifications

CCC,CE, FCC, RoHS

Ethernet Port

Ø  Connector:RJ45

Ø  Data Rate: 10/100/1000M

Ø  Distance: 100m

Ø  UTP Type:UTP-5E or higher level

Fiber Port

Ø  Connector: SC/FC/ST slot

Ø  Data Rate: 1.25Gbps

Ø  Optical wavelength:850nm/1310nm/1490nm/1550nm

Ø  Fiber type:single mode 9/125m,multi-mode 50/125m,62.5/125m

Ø  Distance: 550m~100km

Performance

Ø  Processing Type : Store and Forwarding

Ø  Jumbo Packet: 9216 bytes

Ø  MAC Table: 4K

Ø  Bandwidth: 18G

Ø  Buffer Space: 1M

Ø  Time Delay:<20s

Power

Ø  Power type:external power supply

Ø  Input Voltage:AC100V~240V  50/60Hz

Ø  Connector: DC Socket

Ø  Working Voltage:5V

Ø  Power Consumption: 2.2W~4.5W

Environment

Ø  Storage Temperature:-40~70

Ø  Operating Temperature: -10~55

Ø  Relative Humidity: 5-90% ( no condensation)

Warranty

1  year

Physical Characteristics

Ø  Dimension: 215×107×26mm

Ø  Weight:0.50kg

Ø  Color: Metal,Black
