8 ports 7PoE 65W 1000Mbps data CCTV Camera Switch Plug&Play Network PoE Switch for Camera AP etc Desktop Ethernet Network Switch

Key Features:

1)Comply with IEEE802.3, IEEE802.3u, IEEE802.3af, IEEE802.3at  standards.

2)Provide 7 over-distance ports to support remote transmission of monitoring data. By a over-distance on/off, after on, 1~7 ports work at 10Mbps, and the transmission distance can reach 260m.

3)Provide 2 priority ports to ensure priority transmission of monitoring data.These two priority ports ensure that the port data is preferentially forwarded when the data is congested. The security monitoring device accesses the priority port to ensure the minimum probability of data packet loss and data delay in the event of an emergency. The video is played smoothly in real time.

4)Intelligent flow control mode, intelligent cache, to avoid data loss.

5)Store-and-forward architecture.

6)8* 10/100/1000M adaptive RJ45 ports, support port auto flip (Auto MDI/MDIX).

7)Provides 7 PoE ports, the maximum power of the whole machine is 65W, and the maximum power of a single port is 30W.

8)The UTP port supports auto-negotiation and automatically adjusts the transmission mode and transmission rate.

9)Support MAC address self-learning.

10)Dynamic LED indicator for easy working status prompting and troubleshooting.

11)External power supply, desktop steel shell structure design, support wall mounting.

12)Mini size design for easy placement in the box.
