Matrox C680 2GB GDDR5 PCI Express 3.0 x16 Graphics Card 6x Mini DisplayPort, 6 Monitor Support, 4K Resolution, Single-Slot, 50W, No External Power Required Multi-Display Digital Signage Card

Matrox C680 2GB GDDR5 Professional 6-Display Multi-Monitor Graphics Card

Overview

The Matrox C680 is a professional multi-display graphics card engineered for maximum display density in demanding commercial environments. Designed for digital signage installations, video walls, security operations centers, command & control rooms, and professional A/V applications, this card drives up to six independent 4K displays from a single PCIe slot .

Matrox, a pioneer in multi-display technology, developed the C680 to deliver the stability, flexibility, and performance required for mission-critical multi-monitor deployments. Launched in 2014, this card represents Matrox's transition to AMD GPUs while maintaining their renowned multi-display expertise .

Key Features

6x Mini DisplayPort 1.2 Outputs: At the heart of the C680 are six native Mini DisplayPort 1.2 outputs, each capable of driving resolutions up to 4096 x 2160. With up to three displays, you can enjoy smooth 60Hz refresh rates; when connecting all six displays, each runs at 30Hzperfect for digital signage and static monitoring applications .

2GB GDDR5 Memory: Powered by 2GB of high-speed GDDR5 memory on a 128-bit interface, the C680 handles high-resolution textures and complex multi-display layouts with ease, ensuring smooth performance across all connected screens .

Multi-Card Expansion: For even larger installations, two C680 cards can be combined using board-to-board framelock technology. This allows you to drive up to 12 synchronized displays from a single workstationideal for massive video walls and immersive environments .

Efficient & Compact Design: The single-slot form factor saves valuable space in workstations and servers. With a maximum power draw of just 50 watts, the C680 requires no external PCIe power connectors, making installation quick and hassle-free .

Matrox PowerDesk Software: Included with the C680, Matrox PowerDesk provides a comprehensive suite of desktop management tools. Easily configure bezel compensation, independent desktop modes, extended desktop arrangements, and monitor rotation to match your specific workflow requirements .

Professional-Grade Reliability: Built for 24/7 operation in demanding commercial environments, the C680 is backed by a 3-year manufacturer warranty .

Technical Specifications

Supported Applications & Environments

The Matrox C680 is ideal for:

1. Digital Signage: Power high-resolution digital billboards and in-store displays
2. Video Walls: Create immersive multi-screen environments with bezel compensation
3. Security & Control Rooms: Monitor multiple camera feeds on a single workstation
4. Command & Control: Manage critical operations across an expanded desktop
5. Professional A/V: Drive multiple projectors for presentations and events
6. Enterprise & Industrial: Enhance productivity with multi-display workstations

Key Technologies

1. Matrox PowerDesk: Desktop management software for flexible multi-display configuration
2. Board-to-Board Framelock: Synchronize two C680 cards for tear-free video wall performance
3. DisplayPort 1.2 Multi-Stream Transport (MST): Daisy-chain additional displays from a single output
4. Independent Desktop Mode: Each display operates independently for maximum flexibility
5. Stretched Desktop Mode: Create a single large desktop spanning multiple monitors
6. Clone Mode: Mirror content across multiple displays
7. Bezel Compensation: Adjust for display bezels in video wall configurations
