Silicom NIC Network Server Adapter Dual SFP28 25Gbps PE325G2171-XR-SP

Silicom NIC Network Server Adapter Dual SFP28 25Gbps PE325G2171-XR-SP

Condition New Bulk

Compeve SKU 101000350701

Specifications

SFP28 (Small Form Factor Pluggable) supports: SFI interfaces supports 25GBase-R PCS and 25 Gigabit PMA in order to connect with SFP28 to 25GBase-SR

25GBase-SR SFP28:

IEEE Standard / Network topology: Fiber 25Gigabit Ethernet, 25GBASE-SR (850nM LAN PHY).

25GBase-SR SFP28:

Data Transfer Rate : 25.78125Gbps

25GBase-LR SFP28:

IEEE Standard / Network topology: Fiber 25Gigabit Ethernet, 25GBASE-LR (1310nM LAN PHY)

25GBase-LR SFP28:

Data Transfer Rate: 25.78125Gbps

25GBase-LR SFP28:

Cables and Operating distance Up to: Single-Mode: 10000m at 9um

Interface Standard: PCI-Express Base Specification Revision 3.0 ( 8 GTs)

Board Size: Low profile short add-in card: 145.542mm X 64.389mm (5.730X 2.535)

PCI Express Card Type: X8 Lane

On Board Connector Voltage +12V +/-8%

PCI Connector: X8 Lane

Controllers: Intel XXV710-AM2

Holder: Metal Bracket

Weight: 340gr (12 oz)

Power Consumption (25G-SR) 9.84W, 0.82A at 12V: Typical all ports operate at 25Gb/s,

6.84W, 0.57A at 12V: Typical No link at all ports

Power Consumption (25G-LR) 10.32W, 0.86A at 12V: Typical all ports operate at 25Gb/s,

5.76W, 0.48A at 12V: Typical No link at all ports

Power Consumption (10G-SR) 6.84W, 0.57A at 12V: Typical all ports operate at 10Gb/s,

5.76W, 0.48A at 12V: Typical No link at all ports

Power Consumption (10G-LR) 6.96W, 0.58A at 12V: Typical all ports operate at 10Gb/s,

6.00W, 0.50A at 12V: Typical No link at all ports

Power Consumption (25G-DA) 8.16W, 0.68A at 12V: Typical all ports operate at 25Gb/s,

4.32W, 0.36A at 12V: Typical No link at all ports

Power Consumption (10G-DA) 5.52W, 0.46A at 12V: Typical all ports operate at 10Gb/s,

4.32W, 0.36A at 12V: Typical No link at all ports

Operating Temperature: 0°C 45°C (32°F 113F)

Air Flow Requirements: 200 ft./min

SRIOV Capable: Yes

Storage: -40°C65°C (-40°F149°F)

Compeve DTP#: mrk001
