PCIe x16 PCI-e x16 to TB3 Extension Cable PCI-Express Cables eGPU Adapter Thunderbolt 3 graphics card docking station

Except for laptops, this product also supports NUC motherboards, STX motherboards, ITX motherboards, and Graphics card external use.ADT-Link PCIe x16 PCI-e x16 to TB3 Extension Cable PCI-Express Cables eGPU Adapter

Brand name: ADT-LINK

Product name: PCIe x16 to TB3 extension cable

Product model:

Transfer speed: PCIe3.0 x4 , 32G/bps (Full speed)

Wire length: 25cm, 50cm

Graphics card compatibility: Support new graphics cards that have been out of the factory in the past three years.

Application: eGPU for NUC / ITX / STX / Notebook PC (Only supports thunderbolt3 interface, does not support USB interface).

Package included 1pcs 30cm Thunderbolt 3 type-c cable

Note:

1. The length can be customized, if you need, please contact us.

2. is the Thunderbolt 3 version, Support M.2 NVMe Thunderbolt 3 external box, supports PCIe3.0x4 32G.s full speed.

Cable EMI shielding Description:

EMI Shielding with Conducting Polymer

The extender utilizes the latest materials for EMI shielding with five sole flat cables design. This technique allows each cable to be fully covered by electromagnetic interference shielding with conducting polymer to guard against incoming or outgoing emissions of electromagnetic frequencies, minimize disturbance and degradation on performance, and reduce the weight of the extender.

Cable Length Description:

R3G series cable length has 25 cm or 50 cm can be selected, the following is the line length of 50 cm. refer to the blue dimension of the figure below.

Power Supply Description:

24P_ATX and 4P_CPU power input, Dual 8P_GPU power output.

DELL DA-2 8PIN Input. Dual 8P_GPU power output.
