JVFYI PCIe x1 4-Port USB 3.0 Expansion card NEC720201

Fully compliant with PCI Express Base Specification Revision 2.0

Single-lane (x1) PCI Express throughput rates up to 5 Gbps

Compliant with Universal Serial Bus 3.0 specification Revision 1.0

Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices Supports the following speed data rates as follows: Low-speed (1.5Mbps) / Full-speed (12Mbps) / High-speed (480Mbps) / Super-speed (5Gbps)

External 4x USB3.0 port

Built-in 4-pin power connector for receiving extra power supply from system

Hot-swapping feature allows you to connect/disconnect devices without powering down the system

Support Windows® XP/Vista/7 /8/8.1(32/64 bit),linux

Interface

PCI-Express X1

Connectors:

4 x USB3.0 Connectors

System Requirements

* Windows XP, VISTA, 7 .8.8.1and Server 2008 Release 2 /Linux

* Available PCI-Express X1 slot

Package Contents

1x PCI-Express 4-PORTS USB3.0 Card

1x Manual

1x Driver CD

Hardware Installation

Step 1: Turn off your PC, unplug the power Card and open the case of PC.

Step 2: Remove the mini PCIe Slot cover as below.

Step 3: Plug USB3.0 PCIe card in mini PCIe Slot and install the bracket screw that secures the card to the computer chassis.

Step4: Replace the computer chassis cover ,reconnect the Computer Power Card and turn on your PC.

Driver Installation

For Windows XP, VISTA, 7 and Server 2008 Release 2

1. Please insert the CD driver bound with USB 3.0 4-Port PCI Express Card into your CD-ROM Drive.

2. At the Windows desktop, click Start, Run.

3. TypeUSB3.0 NEC720201-720202\EXE \Setup.exe, click OK.

4. Follow the on-screen instructions to complete the installation.

To Verify Driver Installation

Click on the Device Manager tab in System Properties, which you access from the Windows Control Panel. You should see a NEC USB 3.0 Root Hub and a Renesas Electronics USB3.0 Host Controller under the Universal Serial Bus controllers item.
