    AJMRTC Mini Shield Expansion Board, M.2 2242 SSD Carrier Board for NanoPi NEO Core & Core2, GPIO USB Ethernet Audio Serial Debug for Single Board Computer Embedded IoT Development

    Be the first to review this product...
    • - Purposebuilt mini shield expansion board perfectly compatible with NanoPi NEO Core and NanoPi NEO Core2 SOM modules for embedded hardware building
    • - Supports M.2 2242 SATA SSD via JMS567 controller, delivers highspeed mass storage expansion for system installation and largevolume data saving
    • - Multiple practical onboard interfaces: Gigabit Ethernet, dual USB 2.0 host, 3.5mm audio jack and UART serial debug port for flexible peripheral access
    • - Extended GPIO pin headers reserve abundant signal contacts to connect sensors, relays and other modules for various DIY and IoT projects
    • - Compact PCB with preset mounting holes, stable power circuit, great for prototyping, secondary development and smallsize industrial embedded applications
    +
    +
    Overview
    Specs
    Reviews

    Any questions? Ask CelesteSM will help you find out quickly.

    Try me now

    AJMRTC Mini Shield extension carrier board is a practical expansion hardware tailored for NanoPi NEO Core and NanoPi NEO Core2 systemonmodule boards. Adopting JMS567 USBtoSATA solution, this board accepts M.2 2242 SATA SSD, bringing highperformance expanded storage capacity to your singleboard computer. It integrates gigabit RJ45 Ethernet port for stable wired network connection, two USB 2.0 host ports to hook up keyboards, mice and USB drives, 3.5mm audio jack for audio input and output, as well as UART serial debug header for system debugging and firmware tuning. Fullfeatured breakout GPIO pin headers are exposed, enabling easy hookup with diverse external electronics including sensors and relay units. The optimized power supply circuit guarantees reliable operation, and reserved mounting holes allow secure fixation inside project enclosures. Widely applied in IoT gateway setup, embedded system prototyping, hardware DIY and lightduty industrial secondary development. This expansion board must be matched with NanoPi NEO Core or Core2 core modules for normal function.


    Specifications
    1. Brand: AJMRTC
    2. Compatible SOM: NanoPi NEO Core, NanoPi NEO Core2
    3. SSD Interface: M.2 2242 SATA SSD
    4. Main Controller Chip: JMS567 USBtoSATA
    5. Ethernet: 10/100/1000Mbps Gigabit RJ45
    6. USB Host: 2 × USB 2.0 TypeA
    7. Audio Port: 3.5mm audio jack
    8. Debug Interface: UART serial debug header
    9. GPIO: Extended GPIO pin headers
    10. Mounting Feature: Predrilled mounting holes
    11. Applicable Scenarios: Embedded prototyping, IoT project, SBC secondary development
