MASTECH MS8269 Handheld Digital Multimeter LCR Meter Resistance Capacitance Inductance & Temperature Tester
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Features: Large 2000 Counts LCD Display Tests AC/DC Voltage and Current, Resistance, Frequency and Capacitance Transistor (hFE) Check, Diode and Continuity Test Inductance measurement up to 20H Type K thermocouple contact temperature measurement Data Hold and Display Back Light Safety Rating up to CAT. II 1000V / CAT. III 600V Continuity test
& Diode Test Specification: DC
voltage: 200m/2V/20V/200V 0.5 %, 1000V 0.8 %
AC voltage: 2V/20V/200V 0.8 %, 750V 1.2 %
Resistance: 200/2k/20k/200k/2M 0.8 %, 20M 1.0 %
DC current: 200mA 1.5 %, 10A 2.0 %
AC current: 200mA 1.8 %, 10A 3.0 %
Capacitance: 20n/200n/2/20F/200F 4.0 %
Temperature: -20 C ~ 1000
C Inductance: 20mH/200mH/2H/20H 3.0 %
Transistor hFE: 1 ~ 1000
Specifications: Power
supply: 1 * 6F22 (9V) (not included)
Dimensions: 195 * 92 * 55mm
Package Size: 24 * 17 * 6.5 cm / 9.6 * 6.6 * 2.6 in
Package Weight: 635g / 1.4 lb
Features: Large 2000 Counts LCD Display Tests AC/DC Voltage and Current, Resistance, Frequency and Capacitance Transistor (hFE) Check, Diode and Continuity Test Inductance measurement up to 20H Type K thermocouple contact temperature measurement Data Hold and Display Back Light Safety Rating up to CAT. II 1000V / CAT. III 600V Continuity test
& Diode Test Specification: DC
voltage: 200m/2V/20V/200V 0.5 %, 1000V 0.8 %
AC voltage: 2V/20V/200V 0.8 %, 750V 1.2 %
Resistance: 200/2k/20k/200k/2M 0.8 %, 20M 1.0 %
DC current: 200mA 1.5 %, 10A 2.0 %
AC current: 200mA 1.8 %, 10A 3.0 %
Capacitance: 20n/200n/2/20F/200F 4.0 %
Temperature: -20 C ~ 1000
C Inductance: 20mH/200mH/2H/20H 3.0 %
Transistor hFE: 1 ~ 1000
Specifications: Power
supply: 1 * 6F22 (9V) (not included)
Dimensions: 195 * 92 * 55mm
Package Size: 24 * 17 * 6.5 cm / 9.6 * 6.6 * 2.6 in
Package Weight: 635g / 1.4 lb
& Diode Test Specification: DC
voltage: 200m/2V/20V/200V 0.5 %, 1000V 0.8 %
AC voltage: 2V/20V/200V 0.8 %, 750V 1.2 %
Resistance: 200/2k/20k/200k/2M 0.8 %, 20M 1.0 %
DC current: 200mA 1.5 %, 10A 2.0 %
AC current: 200mA 1.8 %, 10A 3.0 %
Capacitance: 20n/200n/2/20F/200F 4.0 %
Temperature: -20 C ~ 1000
C Inductance: 20mH/200mH/2H/20H 3.0 %
Transistor hFE: 1 ~ 1000
Specifications: Power
supply: 1 * 6F22 (9V) (not included)
Dimensions: 195 * 92 * 55mm
Package Size: 24 * 17 * 6.5 cm / 9.6 * 6.6 * 2.6 in
Package Weight: 635g / 1.4 lb
Features: Large 2000 Counts LCD Display Tests AC/DC Voltage and Current, Resistance, Frequency and Capacitance Transistor (hFE) Check, Diode and Continuity Test Inductance measurement up to 20H Type K thermocouple contact temperature measurement Data Hold and Display Back Light Safety Rating up to CAT. II 1000V / CAT. III 600V Continuity test
& Diode Test Specification: DC
voltage: 200m/2V/20V/200V 0.5 %, 1000V 0.8 %
AC voltage: 2V/20V/200V 0.8 %, 750V 1.2 %
Resistance: 200/2k/20k/200k/2M 0.8 %, 20M 1.0 %
DC current: 200mA 1.5 %, 10A 2.0 %
AC current: 200mA 1.8 %, 10A 3.0 %
Capacitance: 20n/200n/2/20F/200F 4.0 %
Temperature: -20 C ~ 1000
C Inductance: 20mH/200mH/2H/20H 3.0 %
Transistor hFE: 1 ~ 1000
Specifications: Power
supply: 1 * 6F22 (9V) (not included)
Dimensions: 195 * 92 * 55mm
Package Size: 24 * 17 * 6.5 cm / 9.6 * 6.6 * 2.6 in
Package Weight: 635g / 1.4 lb
