PEAKMETER PM2128 Digital AC/DC Clamp Meter Voltage Current Meter Resistance Capacitance Tester

Technical Parameters Range Accuracy DC Voltage 6V/60V600V/1000V (0.5%+5) AC Voltage (45~1000Hz) (45~65Hz) 6V/60V600V/1000V (0.8%+5) 6V/60V600V (0.8%+5) DC Current (40~65Hz) 60A/600A/1000A (2.5%+8) AC Current 60A/600A/1000A (3.0%+10) Resistance 6K/60K/600K/6M/60M (0.8%+3) Continuity <30 Frequency 60Hz/1000Hz (1.0%+5) Temperature -20-1000/-4F-1832 (1.0%+2) Capacitance 60nF-60mF (4.0%+3) Low resistance voltage measurement DCV:1000V ACV:1000V (1.0%+10) (2.0%+20) AC uA 200uA (0.8%+3) Characteristics DIsplay 6000 Voltage Measuring Frequency 1kHz Clamp Measuring Frequency 1kHz Flashlight Yes Backlight Yes Date Hold Yes Non-contact Voltage Detection Yes Continuity Test Yes Auto Power Off 10min Auto/Manual Measurement Yes Relative Value Measurement Yes True RMS Yes DC uA Measurement Yes Inverter Measurement Yes Analog Bar Yes Lowpass Filtering Yes Automatic Identification of Current, Voltage and Resistance Yes General Parameters Brand PEAKMETER Model PM2128 Battery 3 x 1.5V AAA Batteries (NOT included) Item Size 235x85x40mm/9.25x3.35x1.57in Clamp Wodth 35mm/1.38in Weight Approx. 596g Safety Rating EN61010-1, EN61010-2--032, EN61326, CAT.III1000V Features:1. Automatically select measurement function and range.2. Non-contact voltage detection expands use environment.3. LCD display screen can show the measurement data accurately in real time.4. With backlight display and flashlight, convenient to measure at darkness.5. Provides data hold, continuity test, auto power off, analog bar and other functions.6. Can also measure resistance, capacitance, temperature.
