UNI-T UT89XE Digital Multimeter Professional Tester True RMS Manual Range DC AC Voltmeter Ammeter Capacitor Temperature Meter

UT89XE is a manual transmission multimeter with 20000 digits true effective value, high resolution, accurate measurement and complete functions. In addition to the conventional functions, the conductivity measurement function (range 0.1 -200nS, converted resistance is 5-10G) is added, which expands the resistance measurement range and fills in the defect that large resistance cannot be measured; the product is in accordance with CAT Il 1000V/CAT III 600V safety level Design, with over-voltage measurement, over-current alam prompts, all gears are equipped with high-voltage misdetection protection devices. CAT II 1000V/CATIII 600V
Display count: 6000/20000 True RMS Low Pass Filter (LPF) 1000V AC/DC voltage measurement 20A AC and DC current measurement 200M resistance / 200000uF capacitance measurement
AC frequency range: 45~1000Hz
Conductance: 200nS
Temperature measurement range: -10~ 1000.0 /-40 ~ 1832 Peak value/Relative value MAX/MIN
Sampling rate: 3 times/s Audible/visual alarm Capacitor charging indicator Ergonomic design Double injection molding Auto backlight Auto power off/auto backlight Data hold Anti-falling reliability of 1 meter
