Bside ACM91 TRMS AC/DC Clamp Meter Auto-Ranging 6000 Counts 0.001A Current Frequency Temperature Tester with Pocket Clip

AC/DC voltage, AC/DC ampere, AC/DC Current (by jaw minimum 1mA), Temperature, Frequency, Capacitance, DC microampere, Resistance, LIVE wire check, Dangerous voltage alert, with such a small size it meets the rules of the state has made the most perfect functions. LIVE wire check function and V ~ alert function conveniently quickly identify mains connection status. Display double line shows, can display voltage or current and frequency at the same time. LoZ, low impedance voltage detection, very suitable for maintenance industry We optimize the jaw, increased the pens and hustle, easy one-handed operation.

We optimize jack position, better security and aesthetics, reduced the foreign body into the dust. We have added back hooks, convenient to carry
Features: Measure both DC current and AC current (minimum 1mA by jaws) Measure microamps A (minumum 0.1A by terminals) Measure AC and DC voltage Measure frequency Low impedance voltage measurement Measure resistance, continuity and capacitance Measure temperature Live check function V-alert measurement Clamp on frequency function Auto range Data hold Auto power off Back light Conform to the IEC-61010-1, IEC-61010-2-030, IEC-61010-2-032, IEC-61010-2-033 standards Over-voltage protection class CAT III 300V, CAT II 600V, pollution degree
II Specifications:
Display: 6000 counts
DC current: 6A/60A/100A 0.001A / 0.01A / 0.1A ( 3.0 %+5counts)
DC current (uA): 0-200uA 0.1 uA ( 0.8 %+5counts)
AC current: 6A/60A/100A 0.001A / 0.01A / 0.1A ( 2.5 %+5counts)
DC voltage: 6V/60V/600V 0.001V / 0.01V / 0.1V ( 1.0 %+3counts)
AC voltage: 6V/60V/600V 0.001V / 0.01V / 0.1V ( 1.0 %+3counts) Low impedance
LOZ: Max 600V
Resolution 0.1V Resistance: 600/6k/60k/600k/6M ohm 0.1 / 0.001K / 0.01K / 0.1K / 0.001M ohm ( 1.0 %+3counts) 60Mohm 0.01M ohm ( 1.2 %+20counts)
Capacitance: 600uF/6000uF 0.1 uF/1uF ( 4.0 %+3counts)
Frequency: 60Hz/1000Hz 0.1H z/1Hz ( 1.0 %+5counts)
Frequencyby jaws): 60Hz/1000Hz 0.1H z/1Hz ( 1.0 %+5counts)
Buzzer: If the resistance is less than 30, the continuity beeper sounds.
Temperature: -20C~500C 1C/2F ( 2.0 %+2counts)
Jaw Capacity: 20mm
Power: 1.5V (AAA) x 2 (not included)
Size: 179mm x 67mm x 36 mm
Weight: 137g
