Ubiquiti EV Station PRO Electric Vehicle Charging Station (UC-EV-Station-Pro-US)

Ubiquiti EV Station PRO (UC-EV-Station-Pro-US)

Weatherproof, 11 kW Level 2 electric vehicle charging station with an ultra-bright 10.1" touch display, flexible access control, and payment terminal accessory support.

NOTE: UniFi Access must be running on the same console as UniFi Connect with a Control Hub and Access Reader adopted for NFC card registration. Payment Terminal and UniFi WiFi Auto-Link supported with EV Station Pro version 1.2.25 and later. Third-party WiFi configuration is not supported.

Overview:

1. Dimensions: 280 x 178 x 143 mm (11 x 7 x 5.6)
2. Mounting: Wall Mount or Stand
3. Power Input: 200240V ~ 50A, 50/60Hz, 1
4. Power Output: 200240V ~ 50A, 50/60Hz, 1
5. Weatherproofing: Type 3R

Mechanical:

1. Weight: With wall mount/charging gun/power cord: 8.1 kg (17.9 lb)
2. Enclosure Material: Front modules: Polycarbonate
3. Enclosure Material: Middle module: Aluminum, Polycarbonate
4. Mount Material: Polycarbonate
5. Charging Cable Length: 7 m (23 ft)

Hardware:

1. Display Size: 257 mm (10.1") Diagonal
2. Display Resolution: 800 x 1280 (10:16)
3. Display Luminance: 800 nits (typical)
4. Processor: Octa-core Arm Cortex-A53, 2.2 GHz
5. Connectivity: (1) GbE RJ45 port
6. Connectivity: (1) USB-C port for payment terminal accessory
7. Connectivity: Bluetooth 4.2
8. WiFi Standards: 802.11 a/b/g/n/ac

Circuit Rating:

Max. load

1. 70A: 50A
2. 60A: 48A
3. 50A: 40A
4. 40A: 32A
5. 30A: 24A
6. 20A: 16A

Plug-in

1. 70A: No
2. 60A: No
3. 50A: Yes
4. 40A: Yes
5. 30A: Yes
6. 20A: Yes

Hardwired

1. 70A: Yes
2. 60A: Yes
3. 50A: Yes
4. 40A: Yes
5. 30A: Yes
6. 20A: Yes

Software Management Application:

1. UniFi Connect: Version 3.2.4 and later
2. UniFi Connect iOS and Android: Version 2.2.1 and later
