AJMRTC TLC5947 LED Driver Module, 24-Channel 12-Bit PWM Constant Current LED Controller with Internal Oscillator, 3.0V-5.5V Logic Power Supply for LED Display, Lighting Effect and Arduino Projects
- - TLC5947 chip onboard, 24 independent constant current sink channels with 12-bit PWM (4096 brightness grayscale steps)
- - Built-in 4MHz internal oscillator, no external clock signal required for standalone PWM operation
- - Wide logic voltage input 3.0V to 5.5V, compatible with most 3.3V and 5V microcontroller systems
- - Supports cascading multiple modules via serial interface, easy to expand more LED control channels
- - Integrated thermal shutdown protection, automatically cuts off outputs when overheating to protect circuit safety
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
AJMRTC TLC5947 24-channel PWM LED driver breakout board adopts TI TLC5947 chip, providing 24 constant-current sink outputs for precise LED brightness adjustment. Each channel supports 12-bit 4096-level grayscale PWM control, delivering smooth and delicate lighting effects. Thanks to the built-in internal oscillator, the module can work without an external clock source, simplifying wiring design. The board accepts 3.0V to 5.5V logic power, which can directly connect with Arduino, Raspberry Pi and other common MCUs. Serial communication interface supports cascading multiple TLC5947 modules to expand LED quantity conveniently. Built-in thermal shutdown protection prevents damage under over-temperature condition. Ideal for LED matrix display, decorative lighting, stage light effect, embedded lighting control and maker electronic projects.
Specifications
- Product Name: TLC5947 12-Bit 24-Channel PWM LED Driver Module
- Brand: AJMRTC
- Main IC: TLC5947
- PWM Resolution: 12-bit (4096 grayscale levels)
- Channel Count: 24 constant current sink channels
- Logic Voltage: 3.0V ~ 5.5V
- Internal Oscillator: 4MHz
- Max Current per Channel: 30mA
- Communication: Serial interface, cascading supported
- Protection: Thermal shutdown function
- Application: LED matrix, lighting effect control, embedded display project
