Steel Dragon Tools® 1224 1/4" - 4" Power Pipe Threader Threading Machine compatible with RIDGID® 26092 Dies and 711 714 Die Heads

The Steel Dragon Tools® 1224 Pipe Threading Machine will thread, cut, and ream various sizes of water, electric, and gas pipes ranging from 1/4-inch to 4-inch NPT and NPSM threads. The Steel Dragon Tools® 1224 threads a wide range of pipe including black, galvanized, and plastic-coated pipe, as well as stainless steel, IMC, and heavy-wall conduit. The Steel Dragon Tools® 1224 will also thread rod up to 30 Rockwell C.

Specifications:

• The Automatic Geared Self Oiling System will automatically oil dies to extend operating life.


• 1/4-inch to 2-inch Universal Die Head and 2-1/2-inch to 4-inch Receding Die Head will cut tapered or straight NPT and NPSM threads.


• Steel Dragon Tools® 711 and Steel Dragon Tools® 714 Die Heads are compatible with RIDGID® Dies (RIDGID® 26192) (RIDGID® 47765) (RIDGID® 47770)


• The Steel Dragon Tools® 1224 has a 1,500-watt, 2 HP induction motor with extra torque to handle large pipes.


• Foot pedal allows operator to easily control the RPMs while safely operating the machine.


• High-torque, 3-speed induction motor goes in Forward and Reverse for easy cleanup of threads and removal of pipe.

Package Includes:

• Steel Dragon Tools® 1224 Pipe Threading Machine.


• Steel Dragon Tools® 714 universal self-opening die head for 2-1/2 in. to 4 in. pipe. compatible with RIDGID® Dies (NPT/NPSM Threads).


• Steel Dragon Tools® 711 universal self-opening die head for 1/4 in. to 2 in. pipe. compatible with RIDGID® Dies (NPT/NPSM Threads).


• Steel Dragon Tools® 47765 1/2 in. to 3/4 in. universal high-speed dies.


• Steel Dragon Tools® 26192 2-1/2 in. to 4 in. 1224 high-speed dies.


• Steel Dragon Tools® 47770 1 in. to 2 in. high-speed steel dies.


• Steel Dragon Tools® 764 Full Floating Self Centering Pipe Cutter.


• Steel Dragon Tools® 744 Reamer 1/4 in. to 4 in. (blade style).


• Heavy-duty foot pedal with attached plug.


• Includes two (2) extra drive belts.


• Includes four (4) 1-inch steel legs.


• Threading oil is not included.

Technical Specifications:

• Motor: 1,500 W, 2 HP, 110 V, 60 Hz, with FWD/REV, 3-Speed, Induction, High-Torque


• Spindle Speed: 36 RPM (1/4 in. to 3/4 in.), 20 RPM (1 in. to 2 in.), 11 RPM (2-1/2 in. to 4 in.)


• Pipe Capacity: 1/4 in. to 4 in. NPT or NPSM


• All aluminum body.


• Hammer-type chuck with replaceable jaw inserts.


• Cam-action rear-centering chuck.


• HSS Dies Rockwell Hardness (HRC) 58-62


• Maximum Rotation Speed: 36 RPM


• Maximum Chuck Capacity: 4-15/16 in. (125 mm)


• Sledge Travel: 7 in. (180 mm)


• Dimensions: 36 in. (L) x 22 in. (H) x 17 in. (D)


• Weight: 392 lbs.


• Sturdy wooden shipping crate is bolted to the machine for delivery.

To ensure optimal performance and longevity of your pipe threading machine, we recommend greasing and/or lubricating your machine upon arrival and regularly greasing and/or lubricating all moving parts, especially the threading dies and carriage mechanisms. Proper greasing and/or lubrication minimizes wear, reduces friction, and enhances overall machine efficiency. Heavy use of your machine may require more frequent greasing and/or lubrication.
