4K 60Hz Video Capture Card To USB 3.0 Video Capture Board Game Record Live Streaming Broadcast Mic In Audio Out

4K 60Hz Video Capture Card To USB 3.0 Video Capture Board Game Record Live Streaming Broadcast Mic In Audio Out

Matters needing attention:

. This product does not require an external power supply when connected to the standard USB3.0 interface (which can provide 1A current) of the computer. If connected to the USB2.0 interface of the computer or other conditions of insufficient power supply, must be connected to an external power auxiliary power supply, Auxiliary power must be supplied by the attached USB-DC3.5 cable at this point.

. When the audio cable is inserted into the analog audio input port, USB output audio will give priority to analog input audio. If no audio input from the analog audio input port, the input audio will be selected.

. This product supports mobile phone headset access, and the type of headset plug supported is 3.5mm plug of international standard (CTIA).

SPECIFICATIONS:

Model name :4K HD-Video Capture

Input ports :2.0 x1,LINE IN x1,MIC x1,DC3.5 x1

Output ports :2.0 x1,USB3.0 x1, Headset x1

video resolution :720P/1080P/2160P@24/30/50/60Hz

Audio format: LPCM2.0/32~192KHz/16/20/24Bit

Input color space :RGBYUV444YUV422YUV420

Video output resolution: 1920x1080@30Hz Max.

Video output format :YUV or JPEG

input cable length: 2160P/AWG 26 5m or1080P/AWG 26 10m

output cable length :2160P/AWG 26 5m or1080P/AWG 26 10m

Power supply mode: USB power supply / DC5V auxiliary power supply

Max working current: 600mA

Working temperature range: -5 ~ +40

Working humidity range :5 to 85%RHNo Condensation

Size :67*26*13 (mm)
