USB 2.0 Capture Card Practical Durable Convenient Video Recorder Box for PS4 Game DVD Camera Live Stream

Portable Mini USB 2.0 Capture Card Video Recording Box for PS4 Game DVD Camcorder Camera Live Streaming

Introduction:

This USB2.0 capture card can capture audio and video. Audio and video signals can be transmitted to a computer or smartphone for preview and storage. Suitable for high-definition acquisition, teaching recording, medical imaging, etc.

Feature:

Support the highest input resolution up to 4K.

Support the highest output resolution up to 1080P.

Support 8/10/12 bit color depth.

When using standard AWG26 cable, the input transmission distance is up to 15 meters (1080P and below resolution).

Support most acquisition software, such as VLC, OBS, Amcap, etc.

Supports for Windows, Android and MacOS.

Conforms to the USB video UVC specification.

Conforms to the USB audio UAC specification.

No need for external power supply, small size and easy to carry.

Specification:

Resolution: Maximum Input Support 4K

Video Input Format: 8/10/12 Bit Color Depth

Video Output Mode: MJPEG

Video Output Resolution: Maximum 1080P at 30Hz

Support Audio Format: LPCM

Input Transmission Length: 15m, AWG26 Standard Cable

Maximum Working Current: DC 0.4A/5V

Operating Temperature Range: (-10 - +55)

Product Size: 68 X 27 X 9mm/2.68 X 1.06 X 0.35"

Product Weight: 50g

Connection Operation:

1. Connect the signal source and the input port of the USB capture card via 1 cable.

2. Plug the USB header of the USB capture card into the USB port of the computer.

3. Open the acquisition software, the specific settings are as follows:

Note:

1 X Manual
