1080P HDMI To USB 2.0 HD Video Audio Capture Card Standard AWG26 Cable Support Windows Android and MacOS For Teaching Recording

Product introduction:

This USB 2.0 capture card can capture HDMI video and HDMI audio at the same time, and can transmit audio and video signals to a computer or smartphone for preview and storage. Suitable for high-definition acquisition, teaching recording, medical imaging, etc.

Features:

Support maximum input resolution up to 4K;

Support maximum output resolution up to 1080P;

Support 8/10/12 bit color depth;

When using standard AWG26 cable, input transmission distance up to 15 meters (1080P and below resolution);

Support most acquisition software, such as VLC, OBS, Amcap, etc .;

Support Windows, Android and MacOS;

Comply with USB video UVC specifications;

Complies with USB audio UAC specifications;

No external power supply, compact size and easy to carry.

Product Specifications:

specification:

HDMI resolution .................................................. ....... The highest input can support 4K

Video input format ...................................................... ......... 8/10/12 bit color depth

Video output mode ................................................ ............. YUV, JPEG

Video output resolution ........................................... .. Maximum output resolution 1080P

Support audio format ...................................................... ................. L-PCM

Input cable length .............................. 15m, AWG26 HDMI standard cable

Maximum working current ...................................................... ............. 0.4A / 5VDC

range of working temperature............................................... ........ (-10 to + 55 )
