HUBBELL WIRING DEVICE-KELLEMS HBL24W49 Watertight Locking Plug, L6-15P, 15 A,

The HUBBELL 15A Watertight Locking Plug (L6-15P) is an electrical plug rated IP69K for moisture, dust, and weather resistance. It features a smooth body design that minimizes collection points.

Key Features of the HUBBELL 15A Watertight Locking Plug:

• Amperage/Voltage Rating: Rated for 15 A at 250V AC single phase


• NEMA Configuration: L6-15P, locking type with polarized design


• Material Construction: Body and housing made from thermoplastic elastomer; blade and contact material are nickel-plated brass


• Cord Accommodation: Accepts cable diameters from 0.375 in to 0.625 in; compatible with wire sizes ranging from 16/3 SJ to 10/3 SJ, or 18/3 S to 12/3 S


• Ingress Protection: IP69K rated for moisture, dust, and weather resistance; UV stabilized exposed materials


• Operating Temperature Range: -40°C to +60°C continuous operation


• Standards Compliance: Meets ANSI standards as well as NEMA WD-1 and WD-6 requirements


• Performance Ratings: Dielectric strength of up to 2500V AC; current interrupting per UL498; temperature rise limited to max of 30°C at rated current

KEY_TAB
