BANNER Q23SP6RQ Photoelectric Sensor New

Q23 Series: Receiver
Range: 8 m;
Input: 10-30V dc
Output: Complementary PNP 6 in. Pigtail QD
Connector Part Number: 46445 Sensing Beam Visible Red LED Sensing Mode (General) Opposed Sensing Mode (Detailed) Receiver Housing Style Rectangular Primary Housing Material Thermoplastic Input/Output Discrete Max Sensing Distance (mm) 8000 Outputs PNP Power Supply/Supply Voltage 10-30 V dc Connection Pigtail QD Quick Disconnect Type M8 (Pico) Operation Light/Dark Operate Min Op. Temp. (°C) -20 Max Op. Temp. (°C) 55 Output response time (ms) 1
Special Feature: Intrinsically
Safe No Special Feature: Remote
Teach No Special Feature: Water Detection No Delay at Power-up (ms) 100 Repeatability (µs) 130 Number of Pins 4 NEMA Rating NEMA 1, 2, 3, 3S, 4, 4X, 6, 12, 13 IP Rating IP67 Max Op. Relative Humidity [%] 90% @ 50°C Lens Material Acrylic Adjustments Potentiometer Barrel Diameter (mm) N/A Indicator LEDs Opposed Mode Emitter/Receiver
Receiver Feature: Timing (Hold/Delay)
No Feature: Encapsulated
No Feature: Hazardous
Area No Feature: Audible
No Feature: Health/ Marginal Signal Output Yes DeviceNet No
