Adafruit Audio FX Sound Board + 2x2W Amp - WAV/OGG Trigger - 2MB
- No microcontroller required; Comes with a 2 x 2W stereo class D amplifier; Stereo line out - So you can connect up headphones if desired; 11 Triggers - Connect up to 11 buttons or switches, each one can trigger audio files to play; Built in storage - yep! You don't even need an SD card, there's 2MB of storage on the board itself.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Comes with a 2 x 2W stereo class D amplifier No microcontroller required Built in storage - yep! You don't even need an SD card, there's 2MB of storage on the board itself. 11 Triggers - Connect up to 11 buttons or switches, each one can trigger audio files to play Stereo line out - So you can connect up headphones if desired The Adafruit Sound Board, the fastest way to add audio effects to a project! This is the best sound board from Adafruit for props and costumes! Best of all, this version even comes with a 2 x 2W stereo class D amplifier! If you don't need an amplifier built in, check out the headphone-out version here.
The built in storage is good for a few minutes of compressed stereo, and maybe half a minute of uncompressed stereo. Double that if you go with mono instead of stereo. Completely stand-alone, just needs a 3 to 5.5VDC battery Built in Mass Storage USB - Plug any micro USB cable into the Sound Board and your Windows computer, you can drag and drop your files right on as if it were a USB key Compressed or Uncompressed audio - Go with compressed Ogg Vorbis files for longer audio files, or uncompressed WAV files High Quality Sound - You want 44.1KH z 16 bit stereo? Not a problem! The decoding hardware can handle any bit/sample rate and mono or stereo 2 x 2W Class D Amplifier - Get booming instantly, we baked in a stereo amplifier that can drive 4-8 ohm speakers, up to 2.2W with only 1% distortion Five different trigger effects - by changing the name of the files, you can create five different types of triggers which will cover a large range of projects without any programming The sound board is designed to be simple: it does not have polyphonic ability, can't play MP3's, isn't reprogrammable or scriptable, and you can't have any other kind of trigger type. Item Specifics 1 - Audio FX sound board 1 - Header strip 2 - Blue or Black Terminal blocks (2-pin)
Dimensions: 23mm x 51mm x 3mm / 0.9" x 2" x 0.1"
Weight: 4.9 g Batteries, speakers, breadboard, or tactile switches NOT INCLUDED
The built in storage is good for a few minutes of compressed stereo, and maybe half a minute of uncompressed stereo. Double that if you go with mono instead of stereo. Completely stand-alone, just needs a 3 to 5.5VDC battery Built in Mass Storage USB - Plug any micro USB cable into the Sound Board and your Windows computer, you can drag and drop your files right on as if it were a USB key Compressed or Uncompressed audio - Go with compressed Ogg Vorbis files for longer audio files, or uncompressed WAV files High Quality Sound - You want 44.1KH z 16 bit stereo? Not a problem! The decoding hardware can handle any bit/sample rate and mono or stereo 2 x 2W Class D Amplifier - Get booming instantly, we baked in a stereo amplifier that can drive 4-8 ohm speakers, up to 2.2W with only 1% distortion Five different trigger effects - by changing the name of the files, you can create five different types of triggers which will cover a large range of projects without any programming The sound board is designed to be simple: it does not have polyphonic ability, can't play MP3's, isn't reprogrammable or scriptable, and you can't have any other kind of trigger type. Item Specifics 1 - Audio FX sound board 1 - Header strip 2 - Blue or Black Terminal blocks (2-pin)
Dimensions: 23mm x 51mm x 3mm / 0.9" x 2" x 0.1"
Weight: 4.9 g Batteries, speakers, breadboard, or tactile switches NOT INCLUDED
