JVFYI Thunderbolt 3 TO NVMe SSD Adapter

Specification

USB Type-C and Thunderbolt 3 technology: one port to connect them all

Thunderbolt 3 supports up to 4x PCIe 3.0 lanes, 40Gbps data transfer speeds

Actual test speeds for reads were 2600MB / s + and write at 2200MB / s +

Intel JHL6340 Thunderbolt 3 (USB-C) to NVMe M.2 Interface Bridge Chip

Thunderbolt 3 ports only, does not support standard USB-C (USB protocol) ports

Provides devices less than 12W

Supports SSD size size: 2280 (22mm * 80mm)

Supports NVMe M.2 SSDs 4TB or larger

Supports M-Key and B&M-Key NVMe M.2 SSDs, does not support SATA M.2 SSDs, does not support any MacBook Pro / Air / iMac SSDs

Interface type: M.2 NVMe PCI-E to Thunderbolt 3

Windows 8.1 or later

Mac OS X 10.10 or later

PCs or laptops with available Thunderbolt 3 ports

Model Name: Thunderbolt 3 to NVMe SSD Adapter

Interface: Thunderbolt 3

Bus Width: 40Gbps

Transfer Speed Read:2700MB/s Write:1800MB/s

NVMe SSD Size 2280

Hard disk capacity 4TB or Larger

Operating Temperature: 0~70(32F~158F)

Storage Temperature: -50~150(-67F~302F)

Operating Systems: Window: Win8/Win10/Win11 32/64bit

Linux kernel: 3.x/4.x or higher

Mac OS:10.10 or higher

Package content

1 x Thunderbolt 3 TO NVMe SSD Adapter

1 x Users Manual

1 x Thunderbolt 3 cable

System Requirements

Linux Kernels 3.10 and later

Win10/Win11 32 or 64bits

Mac OS 10.10 or later

One available Thunderbolt 3 protocol port

Notice to Users

This product only supports TYPE-C interface devices with Thunderbolt 3 protocol, ordinary TYPE-C interfaces are not supported

Windows computers require the latest BIOS and Thunderbolt drivers to support this product, please contact your computer's manufacturer for updated information.
